Emerson EWD7002 Service Manual

20020301 1-17-1 E5662EL
ELECTRICAL PARTS LIST
PRODUCT SAFETY NOTE:
Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read care-
fully the product safety notice in this service manual.
Don't degrade the safety of the product through
improper servicing.
NOTES:
Parts that are not assigned part numbers (---------) are
not available.
Tolerance of Capacitors and Resistors are noted with
the following symbols.
DVD MAIN CBA UNIT
AV CBA
C.....±0.25% D.....±0.5% F.....±1%
G.....±2% J......±5% K.....±10%
M.....±20% N.....±30% Z.....+80/-20%
Ref. No. Description Part No.
DVD MAIN CBA UNIT N79F0FUP
Ref. No. Description Part No.
AV CBA
Consists of the followings:
0VSA12169
CAPACITORS
C1001# METALLIZED FILM CAP. 0.01µF/275V K or CT2E103HJE05
# METALLIZED FILM CAP. 0.01µF/250V M or CT2E103MS037
# METALLIZED FILM CAP. 0.01µF/250V K CT2E103DC011
C1003 ELECTROLYTIC CAP. 2.2µF/250V M or CA2E2R2S6009
ELECTROLYTIC CAP. 2.2µF/250V M(105°C) CE2EMASTH2R2
C1004 ELECTROLYTIC CAP. 82µF/200V M or CA2D820S6014
ELECTROLYTIC CAP. 82µF/200V M CA2D820NC002
C1005 CERAMIC CAP. CH J 56pF/500V CCD2JJPCH560
C1006# SAFETY CAP. 2200pF/250V or CCG2EMA0F222
# SAFETY CAP. 2200pF/125V or CCG2BMA0E222
# SAFETY CAP. 2200pF/250V CCG2EMA0E222
C1007 ELECTROLYTIC CAP. 2200µF/6.3V M or CE0KMZPDL222
ELECTROLYTIC CAP. 2200µF/10V M CE1AMZPDL222
C1012 ELECTROLYTIC CAP. 100µF/25V M CE1EMASDL101
C1013 CERAMIC CAP.(AX) B K 3300pF/50V CA1J332TU011
C1014 ELECTROLYTIC CAP. 220µF/6.3V M CE0KMASDL221
C1017 CERAMIC CAP.(AX) Y M 0.01µF/16V CCA1CMT0Y103
C1018 ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASDL101
C1021 CHIP CERAMIC CAP. B K 0.01µF/50V CHD1JK30B103
C1022 CHIP CERAMIC CAP. B K 0.01µF/50V CHD1JK30B103
C1029 CERAMIC CAP.(AX) X K 2200pF/16V CCA1CKT0X222
C1031 CERAMIC CAP.(AX) B K 0.01µF/50V CA1J103TU011
C1032 ELECTROLYTIC CAP. 10µF/16V M CE1CMASDL100
C1033 FILM CAP.(P) 0.022µF/50V J or CMA1JJS00223
FILM CAP.(P) 0.022µF/50V J CA1J223MS029
C1035 ELECTROLYTIC CAP. 470µF/16V M CE1CMASDL471
C1036 CHIP CERAMIC CAP. B K 0.01µF/50V CHD1JK30B103
C1037 ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASDL101
C1038 ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASDL471
C1039 ELECTROLYTIC CAP. 47µF/16V M CE1CMASDL470
C1040 ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASDL101
C1041 ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASDL471
C1042 ELECTROLYTIC CAP. 220µF/6.3V M CE0KMASDL221
C1043 CHIP CERAMIC CAP. F Z 0.1µF/50V CHD1JZ30F104
C1046 CHIP CERAMIC CAP. F Z 0.1µF/50V CHD1JZ30F104
C1047 FILM CAP.(P) 0.01µF/50V J or CMA1JJS00103
FILM CAP.(P) 0.01µF/50V J CA1J103MS029
C1048 ELECTROLYTIC CAP. 220µF/16V M CE1CMASDL221
C1049 CHIP CERAMIC CAP. F Z 0.1µF/50V CHD1JZ30F104
C1201 ELECTROLYTIC CAP. 10µF/16V M CE1CMASDL100
C1202 ELECTROLYTIC CAP. 10µF/16V M CE1CMASDL100
C1203 CHIP CERAMIC CAP. CH J 680pF/50V CHD1JJ3CH681
C1204 CHIP CERAMIC CAP. CH J 680pF/50V CHD1JJ3CH681
C1205 CHIP CERAMIC CAP. CH J 390pF/50V CHD1JJ3CH391
C1206 CHIP CERAMIC CAP. CH J 390pF/50V CHD1JJ3CH391
C1207 CHIP CERAMIC CAP. CH D 9pF/50V CHD1JD8CH9R0
C1208 CHIP CERAMIC CAP. CH D 9pF/50V CHD1JD8CH9R0
C1221 ELECTROLYTIC CAP. 10µF/16V M CE1CMASDL100
C1222 ELECTROLYTIC CAP. 10µF/16V M CE1CMASDL100
C1245 CHIP CERAMIC CAP. F Z 0.1µF/50V CHD1JZ30F104
C1246 CHIP CERAMIC CAP. F Z 0.1µF/50V CHD1JZ30F104
C1247 ELECTROLYTIC CAP. 470µF/16V M CE1CMASDL471
C1249 ELECTROLYTIC CAP. 47µF/16V M CE1CMASDL470
C1353 CHIP CERAMIC CAP. B K 0.1µF/25V or CHD1EK30B104
CHIP CERAMIC CAP. B K 0.1µF/16V CHD1CK30B104
C1354 CHIP CERAMIC CAP. CH J 100pF/50V CHD1JJ3CH101
C1356 ELECTROLYTIC CAP. 47µF/6.3V M CE0KMASDL470
C1391 ELECTROLYTIC CAP. 220µF/6.3V M CE0KMASDL221
C1401 CHIP CERAMIC CAP. B K 0.33µF/10V CHD1AK30B334
C1402 ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASDL471
C1421 CHIP CERAMIC CAP. B K 0.01µF/50V CHD1JK30B103
C1422 CHIP CERAMIC CAP. B K 0.1µF/25V or CHD1EK30B104
CHIP CERAMIC CAP. B K 0.1µF/16V CHD1CK30B104
C1441 CHIP CERAMIC CAP. B K 0.33µF/10V CHD1AK30B334
C1442 ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASDL471
C1461 ELECTROLYTIC CAP. 1µF/50V M CE1JMASDL010
C1462 ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASDL471
C1481 ELECTROLYTIC CAP. 1µF/50V M CE1JMASDL010
C1482 ELECTROLYTIC CAP. 470µF/6.3V M CE0KMASDL471
C1522 ELECTROLYTIC CAP. 10µF/16V M CE1CMASDL100
C1523 CHIP CERAMIC CAP. F Z 0.1µF/50V CHD1JZ30F104
C1531 CHIP CERAMIC CAP. B K 0.01µF/50V CHD1JK30B103
C1532 ELECTROLYTIC CAP. 22µF/6.3V M H7 CE0KMASSL220
C2001 CHIP CERAMIC CAP. F Z 0.1µF/50V CHD1JZ30F104
C2002 CHIP CERAMIC CAP. B K 1000pF/50V CHD1JK30B102
C2004 ELECTROLYTIC CAP. 100µF/6.3V M CE0KMASDL101
C2008 ELECTROLYTIC CAP. 22µF/50V M CE1JMASDL220
C2012 CHIP CERAMIC CAP. F Z 0.1µF/50V CHD1JZ30F104
C2055 ELECTROLYTIC CAP. 22µF/50V M CE1JMASDL220
C2057 CHIP CERAMIC CAP. B K 0.1µF/25V or CHD1EK30B104
CHIP CERAMIC CAP. B K 0.1µF/16V CHD1CK30B104
CONNECTORS
CN1001 FMN CONNECTOR, TOP 26P 26FMN-BTRK JCFNG26JG002
CN1601 FMN CONNECTOR, TOP 18P 18FMN-BTK JCFNG18JG001
DIODES
Ref. No. Description Part No.
