Emerson EWD7002 Service Manual

20020301 1-17-2 E5662EL
D1001 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 ND8Z001N4005
D1002 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 ND8Z001N4005
D1003 RECTIFIER DIODE BA157 or NDQZ000BA157
FAST RECOVERY DIODE ERA18-04 QDPZ0ERA1804
D1004 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 ND8Z001N4005
D1005 RECTIFIER DIODE 1N4005 or NDQZ001N4005
RECTIFIER DIODE 1N4005 ND8Z001N4005
D1008 SCHOTTKY BARRIER DIODE ERB81-004 or AERB81004***
SCHOTTKY BARRIER DIODE SB340 NDQZ000SB340
D1009 RECTIFIER DIODE BA157 or NDQZ000BA157
FAST RECOVERY DIODE ERA18-04 QDPZ0ERA1804
D1011 RECTIFIER DIODE BA157 or NDQZ000BA157
FAST RECOVERY DIODE ERA18-04 QDPZ0ERA1804
D1012 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1013 SCHOTTKY BARRIER DIODE SB140 or NDQZ000SB140
SCHOTTKY BARRIER DIODE ERA81-004 QDPZERA81004
D1015 ZENER DIODE DZ-6.8BSBT265 or NDTB0DZ6R8BS
ZENER DIODE MTZJT-776.8B QDTB0MTZJ6R8
D1016 RECTIFIER DIODE BA157 or NDQZ000BA157
FAST RECOVERY DIODE ERA18-04 QDPZ0ERA1804
D1017 ZENER DIODE DZ-22BSBT265 or NDTB00DZ22BS
ZENER DIODE MTZJT-7722B QDTB00MTZJ22
D1018 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1022 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1024 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1025 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1030 RECTIFIER DIODE FR202 or NDQZ000FR202
FAST RECOVERY DIODE ERB32-01L3 QDQZ0ERB3201
D1036 ZENER DIODE DZ-13BSBT265 or NDTB00DZ13BS
ZENER DIODE MTZJT-7713B QDTB00MTZJ13
D1045 SCHOTTKY BARRIER DIODE SB140 or NDQZ000SB140
SCHOTTKY BARRIER DIODE ERA81-004 QDPZERA81004
D1046 ZENER DIODE DZ-5.6BSCT265 or NDTC0DZ5R6BS
ZENER DIODE MTZJT-775.6C QDTC0MTZJ5R6
D1047 ZENER DIODE DZ-5.6BSBT265 or NDTB0DZ5R6BS
ZENER DIODE MTZJT-775.6B QDTB0MTZJ5R6
D1048 ZENER DIODE DZ-12BSBT265 or NDTB00DZ12BS
ZENER DIODE MTZJT-7712B QDTB00MTZJ12
D1049 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D1050 ZENER DIODE DZ-6.2BSBT265 or NDTB0DZ6R2BS
ZENER DIODE MTZJT-776.2B QDTB0MTZJ6R2
D2001 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D2002 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D2003 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
D2004 SWITCHING DIODE 1N4148M or NDTZ01N4148M
SWITCHING DIODE 1SS133(T-77) QDTZ001SS133
ICS
IC1001# PHOTOCOUPLER LTV-817B-F or NPEB0LTV817F
Ref. No. Description Part No.
# PHOTOCOUPLER LTV-817C-F NPEC0LTV817F
IC1002# 1.8V REGULATOR PQ018EF01SZ QSZBA0SSH012
IC1003 IC KIA431-AT NSZLA0TJY001
IC1006 IC KIA431-AT NSZLA0TJY001
IC1201 IC:OP AMP KIA4558P or NSZBA0SJY004
IC NJM4558D QSMLA0STR001
IC1402 DRIVER FOR DVD (6CH) MM1567AJ QSZBA0SMM084
IC2001 FL DRIVER IC PT6315-S(-TP) or NSZBA0TG2002
FL DRIVER IC PT6315-S NSZBA0SG2002
COILS
L1001# LINE FILTER 20MH SA-00911 LLBG00ZSA003
L1006 PCB JUMPER D0.6-P5.0 JW5.0T
L1007 CHOKE COIL 22µH-K LLBD00PKV006
L1008 PCB JUMPER D0.6-P5.0 JW5.0T
L1009 CHOKE COIL 22µH-K LLBD00PKV006
L1011 BEAD CORE B16 RH 3.5X3X1.3 XL03003XM002
L1043 BEAD CORE B16 RH 4X3X2 XL03003XM001
L1060 BEAD CORE B16 RH 3.5X3X1.3 XL03003XM002
L1251 INDUCTOR 0.47µH-K-26T LLAXKATTUR47
L1521 CHOKE COIL 22µH-K LLBD00PKV006
L2001 INDUCTOR 100µH-K-26T LLAXKATTU101
L2002 PCB JUMPER D0.6-P5.0 JW5.0T
L2003 PCB JUMPER D0.6-P5.0 JW5.0T
TRANSISTORS
Q1001 FET 2SK3374 QFWZ02SK3374
Q1002 TRANSISTOR KTC3199(GR) or NQS10KTC3199
TRANSISTOR 2SC2785(H) QQSH02SC2785
Q1003 TRANSISTOR KTC3199(GR) or NQS10KTC3199
TRANSISTOR 2SC2785(H) QQSH02SC2785
Q1004 TRANSISTOR KTC3205(Y) or NQSY0KTC3205
TRANSISTOR 2SC2236-Y-TPE6,C QQSY02SC2236
Q1005 RES. BUILT-IN TRANSISTOR KRC110M-AT or NQSZ0KRC110M
RES. BUILT-IN TRANSISTOR BA1L3Z-T QQSZ00BA1L3Z
Q1006 RES. BUILT-IN TRANSISTOR KRA110M or NQSZ0KRA110M
RES. BUILT-IN TRANSISTOR BN1L3Z(P) QQSP00BN1L3Z
Q1007 TRANSISTOR KTC3205(Y) or NQSY0KTC3205
TRANSISTOR 2SC2236-Y-TPE6,C QQSY02SC2236
Q1008 TRANSISTOR KTC3199(GR) or NQS10KTC3199
TRANSISTOR 2SC2785(H) QQSH02SC2785
Q1011 TRANSISTOR KTA1273(Y) or NQSY0KTA1273
TRANSISTOR 2SA966(Y) QQSY002SA966
Q1014 TRANSISTOR KTC3199(GR) or NQS10KTC3199
TRANSISTOR 2SC2785(H) QQSH02SC2785
Q1201 TRANSISTOR KTC3199(GR) or NQS10KTC3199
TRANSISTOR 2SC2785(H) QQSH02SC2785
Q1202 TRANSISTOR KTC3199(GR) or NQS10KTC3199
TRANSISTOR 2SC2785(H) QQSH02SC2785
Q1203 TRANSISTOR KTA1266(Y) or NQSY0KTA1266
TRANSISTOR 2SA1015-Y(TPE2) QQSY02SA1015
Q1204 TRANSISTOR KTA1266(Y) or NQSY0KTA1266
TRANSISTOR 2SA1015-Y(TPE2) QQSY02SA1015
Q1351 TRANSISTOR KTC3199(GR) or NQS10KTC3199
TRANSISTOR 2SC2785(H) QQSH02SC2785
RESISTORS
R1002 CARBON RES. 1/6W J 1.2k Ω or RCX6JATZ0122
CARBON RES. 1/4W J 1.2k Ω RCX4JATZ0122
R1004 METAL OXIDE FILM RES. 2W J 82k Ω or RN02823ZU001
METAL OXIDE FILM RES. 2W J 82k Ω RN02823KE009
R1005 CARBON RES. 1/4W J 1M Ω RCX4JATZ0105
R1006 CARBON RES. 1/4W J 1M Ω RCX4JATZ0105
Ref. No. Description Part No.
