Emerson EWD7002 Service Manual

20020301 1-17-4 E5662EL
CHIP RES.(1608) 1/16W J 33k Ω RRXGJR5Z0333
R1247 CHIP RES.(1608) 1/10W J 39k Ω or RRXAJR5Z0393
CHIP RES.(1608) 1/16W J 39k Ω RRXGJR5Z0393
R1352 CHIP RES.(1608) 1/10W J 1.6k Ω or RRXAJR5Z0162
CHIP RES.(1608) 1/16W J 1.6k Ω RRXGJR5Z0162
R1353 CHIP RES.(1608) 1/10W J 2.2k Ω or RRXAJR5Z0222
CHIP RES.(1608) 1/16W J 2.2k Ω RRXGJR5Z0222
R1354 CHIP RES.(1608) 1/10W J 2.2k Ω or RRXAJR5Z0222
CHIP RES.(1608) 1/16W J 2.2k Ω RRXGJR5Z0222
R1355 CHIP RES.(1608) 1/10W J 220 Ω or RRXAJR5Z0221
CHIP RES.(1608) 1/16W J 220 Ω RRXGJR5Z0221
R1356 CHIP RES.(1608) 1/10W J 75 Ω or RRXAJR5Z0750
CHIP RES.(1608) 1/16W J 75 Ω RRXGJR5Z0750
R1392 CARBON RES. 1/6W G 150 Ω or RCX6GATZ0151
CARBON RES. 1/4W G 150 Ω RCX4GATZ0151
R1393 CARBON RES. 1/6W G 150 Ω or RCX6GATZ0151
CARBON RES. 1/4W G 150 Ω RCX4GATZ0151
R1394 CARBON RES. 1/6W G 150 Ω or RCX6GATZ0151
CARBON RES. 1/4W G 150 Ω RCX4GATZ0151
R1395 CARBON RES. 1/6W G 150 Ω or RCX6GATZ0151
CARBON RES. 1/4W G 150 Ω RCX4GATZ0151
R1401 CHIP RES. 1/16W F 300 Ω RRXGFR5Z3000
R1402 CHIP RES.(1608) 1/10W J 75 Ω or RRXAJR5Z0750
CHIP RES.(1608) 1/16W J 75 Ω RRXGJR5Z0750
R1421 CHIP RES. 1/16W F 300 Ω RRXGFR5Z3000
R1422 CHIP RES.(1608) 1/10W J 75 Ω or RRXAJR5Z0750
CHIP RES.(1608) 1/16W J 75 Ω RRXGJR5Z0750
R1441 CHIP RES. 1/16W F 300 Ω RRXGFR5Z3000
R1442 CHIP RES.(1608) 1/10W J 75 Ω or RRXAJR5Z0750
CHIP RES.(1608) 1/16W J 75 Ω RRXGJR5Z0750
R1443 CHIP RES.(1608) 1/10W J 75 Ω or RRXAJR5Z0750
CHIP RES.(1608) 1/16W J 75 Ω RRXGJR5Z0750
R1461 CHIP RES. 1/16W F 300 Ω RRXGFR5Z3000
R1462 CHIP RES.(1608) 1/10W J 75 Ω or RRXAJR5Z0750
CHIP RES.(1608) 1/16W J 75 Ω RRXGJR5Z0750
R1481 CHIP RES. 1/16W F 300 Ω RRXGFR5Z3000
R1482 CHIP RES.(1608) 1/10W J 75 Ω or RRXAJR5Z0750
CHIP RES.(1608) 1/16W J 75 Ω RRXGJR5Z0750
R1521 PCB JUMPER D0.6-P5.0 JW5.0T
R2001 CHIP RES.(1608) 1/10W J 56k Ω or RRXAJR5Z0563
CHIP RES.(1608) 1/16W J 56k Ω RRXGJR5Z0563
R2002 CHIP RES.(1608) 1/10W J 10k Ω or RRXAJR5Z0103
CHIP RES.(1608) 1/16W J 10k Ω RRXGJR5Z0103
R2003 CHIP RES.(1608) 1/10W J 10k Ω or RRXAJR5Z0103
CHIP RES.(1608) 1/16W J 10k Ω RRXGJR5Z0103
R2005 CHIP RES.(1608) 1/10W J 4.7k Ω or RRXAJR5Z0472
CHIP RES.(1608) 1/16W J 4.7k Ω RRXGJR5Z0472
R2006 CHIP RES.(1608) 1/10W J 220 Ω or RRXAJR5Z0221
CHIP RES.(1608) 1/16W J 220 Ω RRXGJR5Z0221
R2031 CHIP RES.(1608) 1/10W J 2.2k Ω or RRXAJR5Z0222
CHIP RES.(1608) 1/16W J 2.2k Ω RRXGJR5Z0222
R2032 CHIP RES.(1608) 1/10W J 2.2k Ω or RRXAJR5Z0222
CHIP RES.(1608) 1/16W J 2.2k Ω RRXGJR5Z0222
R2034 CHIP RES.(1608) 1/10W J 2.2k Ω or RRXAJR5Z0222
CHIP RES.(1608) 1/16W J 2.2k Ω RRXGJR5Z0222
R2037 CARBON RES. 1/6W J 10 Ω or RCX6JATZ0100
CARBON RES. 1/4W J 10 Ω RCX4JATZ0100
R2038 CHIP RES.(1608) 1/10W J 10k Ω or RRXAJR5Z0103
CHIP RES.(1608) 1/16W J 10k Ω RRXGJR5Z0103
R2039 CHIP RES.(1608) 1/10W J 10k Ω or RRXAJR5Z0103
CHIP RES.(1608) 1/16W J 10k Ω RRXGJR5Z0103
Ref. No. Description Part No.
R2059 CHIP RES.(1608) 1/10W 0 Ω or RRXAZR5Z0000
CHIP RES.(1608) 1/16W 0 Ω RRXGZR5Z0000
SWITCHES
SW2011 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A SST0101AL041
SW2012 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A SST0101AL041
SW2013 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A SST0101AL041
SW2014 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A SST0101AL041
SW2015 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A SST0101AL041
SW2016 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A SST0101AL041
SW2017 TACT SWITCH KSM0614B or SST0101HH013
TACT SWITCH SKQSAF001A SST0101AL041
MISCELLANEOUS
2B4 EARTH PLATE S H9000UD 0VM411284
AC1001# AC CORD A0A0280-007 or WAC0172LTE04
# AC CORD PB8K9F9110A-057 WAC0172LW008
F1001# FUSE 1A/250V or PAGA20CW3102
# FUSE 1A/250V PAGG20CAG102
FH1001 FUSE HOLDER MSF-015 XH01Z00LY001
FH1002 FUSE HOLDER MSF-015 XH01Z00LY001
FL2001 V.F.D. 20U29100SAN TVFD150FT007
JK1201 3PIN JACK MSP-253V1-14 PBSN or JXRL030LY058
3PIN JACK WSP253V1-43 JXRL030WEL07
JK1401 S TYPE JACK MDC-050V-2.4 JXEL040LY001
JK1403 RCA JACK MSP-244V10-46 PBSN JXRL040LY042
RM2001 REMOTE RECEIVER PIC-37042LU USESJRSKK033
SA1001# SURGE ABSORBER PVR-10D471KB or NVQZ10D471KB
# SURGE ABSORBER CNR-10D471K or NVQZR10D471K
# SURGE ABSORBER JVR-10N471K NVQZR10N471K
T1001# PULSE TRANS CSA-SW0061 LTT00CPSA119
W1001 26P FFC AV PCB TO MAIN WX1E5600-001
W1601 18P FFC WX1E5600-005
Ref. No. Description Part No.
