Instruction Manual
D100306X012
657 Actuator (30/30i-70/70i and 87)
June 2018
2
Table 1. Specifications
SPECIFICATION
(1)
ACTUATOR SIZE
30/30i 34/34i 40/40i 45/45i 46/46i 50/50i 60/60i 70/70i
(1)
87
(1)
Nominal Effective Area
cm
2
297 445 445 677 1006 677 1006 1419 1419
Inch
2
46 69 69 105 156 105 156 220 220
Yoke Boss Diameters
mm 54 54 71 71 71 90 90 90 127
Inches 2‐1/8 2‐1/8 2‐13/16 2‐13/16 2‐13/16 3‐9/16 3‐9/16 3‐9/16 5
Acceptable Valve
Stem Diameters
mm 9.5 9.5 12.7 12.7 12.7 19.1 19.1 19.1 25.4
Inches 3/8 3/8 1/2 1/2 1/2 3/4 3/4 3/4 1
Maximum Allowable
Output Thrust
(4)
N 10230 10230 12010 25131 33582 25131 30246 39142 39142
Lb 2300 2300 2700 5650 7550 5650 6800 8800 8800
Maximum Travel
(2)
mm 19 29 38 51 51 51 51 76
(3)
76
(3)
Inches 0.75 1.125 1.5 2 2 2 2 3
(3)
3
(3)
Maximum Casing
Pressure for
Actuator Sizing
(4)
Bar 8.6 4.5 4.5 3.4 2.8 3.4 2.8 3.8 3.8
Psig 125 65 65 50 40 50 40 55 55
Maximum Diaphragm
Casing Pressure
(4)(5)
Bar 9.6 5.2 5.2 4.1 3.4 4.1 3.4 4.5 4.5
Psig 140 75 75 60 50 60 50 65 65
Material Temperature
Capabilities
_C Nitrile Elastomers: -40 to 82_C, Silicone Elastomers: -54 to 149_C, Fluorocarbons: -18 to 149_C
_F Nitrile Elastomers: -40 to 180_F, Silicone Elastomers: -65 to 300_F, Fluorocarbons: 0 to 300_F
Pressure Connections
(internal)
1/4 NPT X X X X X X X ‐ ‐ ‐ ‐ ‐ ‐
1/2 NPT ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ X X
Approximate Weights
kg 16/17 22/25 23/25 37/40 49/52 42/45 53/56 107/109 116
Lb 36/38 48/54 51/56 82/84 107/114 92/99 116/125 235/240 255
1. These values also apply to the 657‐4 actuator construction.
2. Actuator travel may be less than the value listed after connecting the actuator to the valve.
3. Maximum travel for 657‐4 is 102 mm (4 inches).
4. Normal operating diaphragm pressure must not exceed maximum diaphragm casing pressure and must not produce a force on the actuator stem greater than the maximum allowable out
put thrust or the maximum allowable valve stem load. Contact your Emerson sales office
or Local Business Partner with questions concerning maximum allowable valve stem load.
5. This maximum casing pressure is not to be used for normal operating pressure. Its purpose is to allow for typical regulator supply settings and/or relief valve tolerances.
Description
The 657 actuator (figure 1) and the 657‐4 actuator are direct‐acting, spring‐opposed diaphragm actuators. They
provide automatic operation of control valve body assemblies. The 657 actuator offers 76 mm (3 inches) maximum
actuator travel. The 657‐4 actuator provides 102 mm (4 inches) maximum actuator travel. Both actuators position the
valve plug in response to varying pneumatic loading pressure on the actuator diaphragm. Figure 2 shows the
operation of these actuators.
A 657 or 657‐4 actuator can be equipped with either a top‐mounted or a side‐mounted handwheel assembly. A
top‐mounted handwheel assembly is used as an adjustable up travel stop to limit actuator travel in the up direction
(see figure 2). A side‐mounted handwheel assembly is usually used as an auxiliary manual actuator. Adjustable
casing‐mounted up or down travel stops are also available for this actuator.
Note
If repeated or daily manual operation is expected, the actuator should be equipped with a side‐mounted handwheel rather than a
casing‐mounted travel stop or top‐mounted handwheel.
The side‐mounted handwheel is designed for more frequent use as a manual operator.
Specifications
Refer to table 1 for Specifications of the 657 and 657‐4 actuators. See the actuator nameplate for specific information
about your actuator.
