Emerson Fisher EWT User Manual

Instruction Manual
D100399X012
EW Valve
July 2017
37
Key Description Part Number
S31600 for chrome moly steel or
316 SST bonnet
16 ENVIRO‐SEAL bellows seal pipe plug
(2 req'd)
20* ENVIRO‐SEAL bellows seal stem/bellows
assembly
1 ply bellows
S31603 (316L SST) trim, N06625
bellows
Size 4x2 w/ 12.7 mm (1/2 inch) stem 32B4226X012
Size 6x4x2‐1/2, 6x4, & 8x4
w/ 12.7 mm (1/2 inch) stem 32B4228X012
N06022 trim, N06022
bellows
Size 4x2 w/ 12.7 mm (1/2 inch) stem 32B4226X022
Size 6x4x2‐1/2, 6x4, & 8x4
w/ 12.7 mm (1/2 inch) stem 32B4228X022
20* ENVIRO‐SEAL bellows seal stem/bellows
assembly (cont'd)
2 ply bellows
S31603 (316L SST) trim, N06625
bellows
Size 4x2 w/ 12.7 mm (1/2 inch) stem 32B4226X032
Size 6x4x2‐1/2, 6x4, & 8x4
w/ 12.7 mm (1/2 inch) stem 32B4228X032
Key Description Part Number
N06022 trim, N06022
bellows
Size 4x2 w/ 12.7 mm (1/2 inch) stem 32B4226X042
Size 6x4x2‐1/2, 6x4, & 8x4
w/ 12.7 mm (1/2 inch) stem 32B4228X042
22* ENVIRO‐SEAL bellows seal bonnet gasket,
graphite/laminate
Size 4x2 valve 12B6318X022
Size 6x4x2‐1/2, 6x4, & 8x4 valve 12B6320X022
24 ENVIRO‐SEAL bellows seal adaptor
25 Cap Screw for 127 mm (5 inch) yoke boss,
steel (8 req'd)
Size 12x8 valve, CL900
26 Hex Nut for 127 mm (5 inch) yoke boss,
pl steel (8 req'd)
27 Pipe Nipple for lubricator/isolating valve
28 Warning Nameplate for ENVIRO‐SEAL bellows
29 Drive Screw for ENVIRO‐SEAL bellows, stain‐
less steel (2 req'd)
36* ENVIRO‐SEAL bellows seal pin, N06022 12B3951X012
37 Warning Tag for ENVIRO‐SEAL bellows
38 Tie for ENVIRO‐SEAL bellows
39 ENVIRO‐SEAL bellows seal thrust ring
Trim S31600
Single PTFE Packing
Size 4x2 w/ 12.7 mm (1/2 inch) stem
(2 req'd)
Keys 6
*
, 7
*
, 8, and 10 Packing Box Parts
DESCRIPTION KEY NO.
STEM DIAMETER, mm (INCHES)
12.7 (1/2) 19.1 (3/4) 25.4 (1) 31.8 (1‐1/4)
PTFE V‐Ring Packing
Packing Set, PTFE (1 req'd for single, 2
req”d for double)
(1)
6 1R290201012 1R290401012 1R290601012 1R290801012
Spring, Stainless Steel
(for single only)
8 1F125537012 1F125637012 1D582937012 1D387437012
Lantern Ring, Stainless Steel
(for double only)
8 1J269335072 0N028435072 0U099735072 0W087135072
Quantity required Double ‐ ‐ ‐ 2 1 1 1
Special washer, Stainless Steel (for
single only)
10 1F125136042 1F125036042 1H982236042 1H995936042
PTFE/composition
Packing
Packing Ring, PTFE composition 7 1E319001042 1E319101042 1D7518X0012 1D7520X0012
Quantity required Double ‐ ‐ ‐ 10 8 8 8
Lantern Ring, Stainless Steel (1 req'd) 8 1J9623 35072 0N028435072 0U099735072 0W087135072
Graphite
Ribbon/Filament
Graphite Ribbon Ring 7 1V3802X0022 1V2396X0022 1U6768X0022 1V5666X0022
Quantity required
Single ‐ ‐ ‐ 2 2 2 2
Double ‐ ‐ ‐ 3 3 3 3
Graphite Filament Ring 7 1E3190X0222 1E3191X0282 1D7518X0132 1D7520X0162
Quantity required
Single ‐ ‐ ‐ 2 3 3 3
Double ‐ ‐ ‐ 4 5 5 5
Lantern Ring 8 1J962335072 0N028435072 0U099735072 0W087135072
Quantity required
Single ‐ ‐ ‐ 3 2 2 2
Double ‐ ‐ ‐ 2 1 1 1
1. Key 6 for double construction contains one extra Lower Wiper for all sizes. Discard upon assembly.
*Recommended spare parts
