Instruction Manual
D100399X012
EW Valve
July 2017
33
Parts Kits
Gasket Kits
Gasket Kits (includes keys 10, 12, 13, and 53; plus 11 and 14 for restricted trim)
VALVE SIZE, NPS
Standard Trim Cage
Whisper Trim I Cage
Cavitrol III - 1 Stage Cage
Cavitrol III - 2 Stage Cage
Whisper Trim III Cage
WhisperFlo Cage
-198 to 593_C (-325 to 1100_F) -198 to 593_C (-325 to 1100_F)
Part Number Part Number
4x2 RGASKETX182 RGASKETX442
6x4x2‐1/2 RGASKETX282 - - -
6x4 or 8x4 RGASKETX212 RGASKETX472
8x6 or 12x6
CL300, CL600, or CL900
RGASKETX392 - - -
8x6 or 12x6
Whisper Trim I
RGASKETX412
(1)
- - -
10x8 or 12x8 RGASKETX232 10A3265X152
1. Includes a quantity 2 of key 10.
Packing Kits
Standard Packing Repair Kits
Packing repair kits for standard packing include keys 6, 8, 10, 11 and 12.
Note
Kits do not apply to alloy C (N10276 and CW2M), Alloy 20 (N08020 and CN7M), or alloy 400 (N04400 and M35‐1) trims.
Standard Packing Repair Kits (Non Live‐Loaded)
Stem Diameter, mm (Inches)
Yoke Boss Diameter, mm (Inches)
12.7 (1/2)
71 (2‐13/16)
19.1 (3/4)
90 (3‐9/16)
25.4 (1)
127 (5)
31.8 (1-1/4)
127 (5, 5H)
PTFE (Contains keys 6, 8, 10, 11, and 12) RPACKX00022 RPACKX00032 RPACKX00342 RPACKX00352
Double PTFE (Contains keys 6, 8, 11, and 12) RPACKX00052 RPACKX00062 RPACKX00362 RPACKX00372
PTFE/Composition (Contains keys 7, 8, 11, and 12) RPACKX00082 RPACKX00092 - - - - - -
Single Graphite Ribbon/Filament (Contains keys 7 [ribbon ring],
7 [filament ring], 8, and 11)
RPACKX00112 RPACKX00122 - - - - - -
Single Graphite Ribbon/Filament (Contains keys 7 [ribbon ring],
7 [filament ring], and 11)
- - - - - - RPACKX00532 RPACKX00542
Single Graphite Ribbon/Filament (Contains keys 7 [ribbon ring],
7 [filament ring])
RPACKX00142 RPACKX00152 - - - - - -
Double Graphite Ribbon/Filament (Contains keys 7 [ribbon ring],
7 [filament ring], 8, and 11)
RPACKX00172 RPACKX00182 - - - - - -
