Instruction Manual
D100399X012
EW Valve
July 2017
34
HIGH‐SEAL and ENVIRO‐SEAL Packing Retrofit Kits
Retrofit kits include parts to convert valves with existing standard bonnets to the HIGH‐SEAL or ENVIRO‐SEAL packing
box construction. Refer to figure 17 for key numbers for HIGH‐SEAL packing. For ENVIRO‐SEAL packing, refer to figure
18 for PTFE packing key numbers, figure 19 for Graphite ULF packing key numbers, and figure 20 for duplex packing
key numbers.
Stems and packing box constructions that do not meet Emerson stem finish specifications, dimensional tolerances,
and design specifications, may adversely alter the performance of this packing kit.
HIGH‐SEAL Packing Retrofit Kits
Stem Diameter, mm (Inches)
Yoke Boss Diameter, mm (Inches)
12.7 (1/2)
71 (2‐13/16)
19.1 (3/4)
90 (3‐9/16)
25.4 (1)
127 (5)
31.8 (1‐1/4)
127 (5, 5H)
4200 psi Process Pressure Rating (Contains keys 200
through 212)
11B2182X052 11B2184X052 11B2187X052 11B2189X052
ENVIRO‐SEAL Packing Retrofit Kits
Stem Diameter, mm (Inches)
Yoke Boss Diameter, mm (Inches)
12.7 (1/2)
71 (2‐13/16)
19.1 (3/4)
90 (3‐9/16)
25.4 (1)
127 (5)
31.8 (1‐1/4)
127 (5, 5H)
Double PTFE (Contains keys 200, 201, 211, 212, 214,
215, 217, 218, tag, cable tie)
RPACKXRT022 RPACKXRT032 RPACKXRT042 RPACKXRT052
Graphite ULF (Contains keys 200, 201, 207, 208, 209,
210, 211, 212, 214, 217, tag, cable tie)
RPACKXRT272 RPACKXRT282 RPACKXRT292 RPACKXRT302
Duplex (Contains keys 200, 201, 207, 209, 211, 212,
214, 215, 216, 217, tag, cable tie)
RPACKXRT222 RPACKXRT232 RPACKXRT242 RPACKXRT252
ENVIRO‐SEAL Packing Repair Kits
Repair kits include parts to replace the ”soft” packing materials in valves that already have ENVIRO‐SEAL packing
arrangements installed or in valves that have been upgraded with ENVIRO‐SEAL retrofit kits. Refer to figure 18 for key
numbers for PTFE packing, figure 19 for key numbers for Graphite ULF packing, and figure 20 for key numbers for
duplex packing.
Stems and packing box constructions that do not meet Emerson stem finish specifications, dimensional tolerances,
and design specifications, may adversely alter the performance of this packing kit.
ENVIRO‐SEAL Packing Repair Kits
Stem Diameter, mm (Inches)
Yoke Boss Diameter, mm (Inches)
12.7 (1/2)
71 (2‐13/16)
19.1 (3/4)
90 (3‐9/16)
25.4 (1)
127 (5)
31.8 (1‐1/4)
127 (5, 5H)
Double PTFE (Contains keys 214, 215, 218) RPACKX00202 RPACKX00212 RPACKX00222 RPACKX00232
Graphite ULF (Contains keys 207, 208, 209, 210, 214) RPACKX00602 RPACKX00612 RPACKX00622 RPACKX00632
Duplex (Contains keys 207, 209, 214, 215) RPACKX00302 RPACKX00312 RPACKX00322 RPACKX00332
