Emerson Fisher EWT User Manual

Instruction Manual
D100399X012
EW Valve
July 2017
35
Figure 17. Typical Fisher HIGH‐SEAL Packing System
A6138
STUD
(KEY 200)
HEX NUT
(KEY 212)
PACKING
FLANGE
(KEY 201)
SPRING
(KEY 202)
PACKING RING
(KEY 209)
GRAPHITE RIBBON
PACKING RING
(KEY 210)
PACKING
BOX RING
(KEY 211)
SCREW
(KEY 204)
LOAD
SCALE
(KEY 205)
INDICATOR
DISK
(KEY 206)
PACKING
FOLLOWER
(KEY 203)
GUIDE
BUSHING
(KEY 207)
GUIDE
BUSHING
(KEY 208)
Figure 18. Typical Fisher ENVIRO‐SEAL Packing
System with PTFE Packing
A6297‐1
Figure 19. Typical Fisher ENVIRO‐SEAL Packing
System with Graphite ULF Packing
39B4612/A
Figure 20. Typical Fisher ENVIRO‐SEAL Packing
System with Duplex Packing
200
212
201
215
216
207
209
211
217
207
207
207
214
213
A6722
