Instruction Manual
D100399X012
EW Valve
July 2017
48
Figure 29. Typical Fisher WhisperFlo Trims
DISK SEAT
EWD/EWT
(METAL SEAT)
EWT
(SOFT SEAT)
DISK
DISK RETAINER
WhisperFlo CAGE
CAGE RETAINER
BONNET SPACER
SEAT RING
SEAT RING
DISK SEAT
DISK
DISK RETAINER
WhisperFlo CAGE
CAGE RETAINER
BONNET SPACER
EWD CLASS IV
(METAL SEAT)
EWT WITH
SPRING‐LOADED SEAL RING
(SOFT SEAT)
