Emerson Fisher EWT User Manual

Instruction Manual
D100399X012
EW Valve
July 2017
54
C‐seal Parts for Fisher EWD Valve (Keys 3*, 2*, 9*, 64*, 6*, and 7*) (continued)
VALVE
SIZE
PORT
DIA
TRAVEL
TRIM
STEM
DIA
CHARACTER‐
ISTIC
CAGE
PLUG/
RETAINER
SEAT RING C‐seal PISTON RING STEM
NPS Inch Inch
mm
(Inch)
Key 3 Key 2 Key 9 Key 64 Key 6 Key 7
10X8 8
3 1
19.1
(3/4)
Linear 37B1663X022
37B6392X022 29A9704X012 34B9827X012 24B9826X012 1K5880X0262
(1)
Equal % 37B5635X022
25.4
(1)
Linear 37B1663X022
37B6392X012 29A9704X012 34B9827X012 24B9826X012 10A3282X222
(2)
Equal % 37B5635X022
2
1
25.4
(1)
Whisper I 47B6378X012
37B6389X012 29A9704X012 34B9827X012 24B9826X012
10A3282X222
(2)
3.5
(3)
Whisper I 47B5214X012 1K7783X0032
(2)
2
31.8
(1‐1/4)
Whisper I 47B6378X012
37B6379X012 29A9704X012 34B9827X012 24B9826X012
10A6073X072
(2)
3.5
(3)
Whisper I 47B5214X012 ‐ ‐ ‐
(2)
3 3H
19.1
(3/4)
Linear 37B1663X012
37B1665X032 29A9704X022 34B9827X012 24B9826X012 1K5880X0262
(1)
Equal % 37B5635X012
25.4
(1)
Linear 37B1663X012
37B1665X012 29A9704X022 34B9827X012 24B9826X012 10A3282X222
(2)
Equal % 37B5635X012
31.8
(1‐1/4)
Linear 37B1663X012
37B1665X022 29A9704X022 34B9827X012 24B9826X012 1L2298X0202
(2)
Equal % 37B5635X012
10X8 8
3
37H
19.1
(3/4)
Linear 37B1663X022
37B1665X032 29A9704X022 34B9827X012 24B9826X012 1K5880X0262
(1)
Equal % 37B5635X022
25.4
(1)
Linear 37B1663X022
37B1665X012 29A9704X022 34B9827X012 24B9826X012 10A3282X222
(2)
Equal % 37B5635X022
31.8
(1‐1/4)
Linear 37B1663X022
37B1665X022 29A9704X012 34B9827X012 24B9826X012 1L2298X0202
(2)
Equal % 37B5635X022
2
25.4
(1)
Whisper I 47B6378X012
34B9848X012 29A9704X012 34B9827X012 24B9826X012
10A3282X222
(2)
3.5
(3)
Whisper I 47B5214X012 1K7783X0032
(2)
2
31.8
(1‐1/4)
Whisper I 47B6378X012
‐ ‐ ‐ 29A9704X012 34B9827X012 24B9826X012
10A6073X072
(2)
3.5
(3)
Whisper I 47B5214X012 ‐ ‐ ‐
(2)
12X8 8 3 3H
25.4
(1)
Linear 37B1663X012
37B1665X012 29A9704X022 34B9827X012 24B9826X012 10A3282X222
Equal % 37B5635X012
31.8
(1‐1/4)
Linear 37B1663X012
37B1665X022 29A9704X022 34B9827X012 24B9826X012 10A3282X222
Equal % 37B5635X012
1. For Standard Bonnet.
2. For Style 1 Extension Bonnet.
3. Requires bonnet spacer 34B1369.
TSO Parts for Fisher EWT Valve (Keys 3*, 9*, 2*, 28*, 63*, 29*, and 27*)
(1)
VALVE
SIZE
PORT
DIA
STEM
DIAMETER
CHARAC‐
TERISTIC
CAGE SEAT RING
PLUG/
STEM ASSY
SEAL RING
ANTI‐EXT
RING
BACKUP RING
RETAINING
RING
NPS Inch mm Inch Key 3 Key 9 Key 2 Key 28 Key 63 Key 29 Key 27
6x4 4.1875 19.1 3/4
Linear 2U236633272
38B0278X012 38B0282X012 10A4223X142 21B9341X012 10A4224X012 10A4225X012
Equal % 2U236333272
Quick Open 2U236033272
Whisper 23A8915X032
8x4 4.1875 19.1 3/4
Linear 2U236633272
38B0279X012 38B0282X012 10A4223X142 21B9341X012 10A4224X012 10A4225X012
Equal % 2U236333272
Quick Open 2U236033272
Whisper 23A8915X032
8x6 6.8125 19.1 3/4
Linear 2U505933272
38B0280X012 38B0284X012 10A2643X112 22B5998X012 12B5997X012 14A4652X012
Equal % 2U506133272
Quick Open 2U506333272
Whisper 23A8913X032
12x6 6.8125 19.1 3/4
Linear 2U505933272
38B0281X012 38B0284X012 10A2643X112 22B5998X012 12B5997X012 14A4652X012
Equal % 2U506133272
Quick Open 2U506333272
Whisper 23A8913X032
1. Travel is 2‐Inch. Trim is 812.
*Recommended spare parts
