Emerson Fisher EWT

Instruction Manual
D100399X012
EW Valve
July 2017
56
Key 7
*
Valve Stem (except for Cavitrol III constructions)
VALVE SIZE, NPS
STEM DIA
ACTU‐
ATOR
GROUP
BONNET
Plain Style 1 Extension
Style 2
Extension
mm Inch
S31600
(316 SST)
S31600
Cr Pl
(1)
S31600
S31600
Cr Pl
(1)
S31600
4x2
12.7 1/2 1 1K586935162 1K586946592 1U226335162 1U226346592 1U226435162
19.1 3/4 1 1U226535162 1U226546592 1L400135162 1L400146592 ‐ ‐ ‐
6x4x2‐1/2
12.7 1/2 1 1P669335162 1P669346592 1K587335162 1K587346592 1V782535162
19.1 3/4 1 1K587735162 1K587746592 1V782435162 1V782446592 1V240035162
6x4 or 8x4
12.7 1/2 1 1U230535162 1U230546592 1U230635162 1U230646592 1U230735162
(3)
19.1 3/4 1 1K587735162 1K587746592 1U444635162 1U444646592 1U240035162
25.4 1 100 1U217535162 1U217546592 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐
25.4 1 101 1K759035162 1K759046592 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐
8x6
CL300
or
CL600,
except
for
Whisper
Trim III
cages
51 mm
(2‐Inch)
travel
19.1 3/4 1 1L996435162 1L996446592 1U507135162 1U507146592 1U524435162
25.4 1 100 1N704735162 1N704746592 1K785135162 1K785146592 ‐ ‐ ‐
25.4 1 101 1K759135162 1K759146592
(3)
1P597335162
(3)
1P597346592
(3)
‐ ‐ ‐
31.8 1‐1/4 100 1K415435162 1K415446592 1R562435162 1R562446592 ‐ ‐ ‐
31.8 1‐1/4 101 1K775335162 1K775346592 1U316235162 1U316246592
76 mm
(3‐Inch)
travel
19.1 3/4 1 1U293835162 ‐ ‐ ‐ 1U928235162 ‐ ‐ ‐ ‐ ‐ ‐
25.4 1 100, 101 1N704735162 1N704746592 1K785135162 1K785146592 ‐ ‐ ‐
31.8 1‐1/4 100, 101 1K415435162 1K415446592 1N770735162 ‐ ‐ ‐ ‐ ‐ ‐
102 mm
(4‐Inch)
travel
19.1 3/4 1, 403 1U294135162 ‐ ‐ ‐ 10A9265X552 ‐ ‐ ‐ 10A9265X562
8x6
CL900
51 mm
(2‐Inch)
travel
19.1 3/4 1 1K588035162 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐
25.4 1 100 1K778335162 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐
25.4 1 101
1L2687X0012
(2)
‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐
1N325635162
(3)
‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐
31.8 1‐1/4
100 1U9886X0012 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐
101 1U316235162 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐
76 mm
(3‐Inch)
travel
19.1 3/4 1 1K588035162 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐
25.4 1 100, 101 1N325635162 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐
31.8 1‐1/4 100, 101 1U316235162 ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐ ‐
12x6
except
for
Whisper
Trim III
cages
51 or
76 mm
(2 or
3‐Inch)
travel
19.1 3/4 1 1L996435162 1L996446592 1U507135162 1U507146592 1U524435162
25.4 1
100 1N704735162 1N704746592 1K785135162 1K785146592 ‐ ‐ ‐
101 1K759135162 1K759146592 1P597335162
(4)
1P597346592
(4)
‐ ‐ ‐
31.8 1‐1/4
100 1K415435162 1K415446592 1R562435162 1R562446592 ‐ ‐ ‐
101 1K775335162 1K775346592 1U316235162 1U316246592 ‐ ‐ ‐
102 mm
(4‐Inch)
travel
19.1 3/4 1, 403 1U294135162 ‐ ‐ ‐ 10A9265X552 ‐ ‐ ‐ 10A9265X562
10x8
51 mm
(2‐Inch)
travel
19.1 3/4 1 1K588035162 1K5880X0262 1U928235162 1U9282X0192 ‐ ‐ ‐
25.4 1 100 1K7891X0012 ‐ ‐ ‐ 1K7891X0012 ‐ ‐ ‐ ‐ ‐ ‐
76 mm
(3‐Inch)
travel
25.4 1 100, 101 10A3282X012 ‐ ‐ ‐ 10A3282X012 ‐ ‐ ‐ ‐ ‐ ‐
31.8 1‐1/4 100 1L2298X0012 ‐ ‐ ‐ 1L2298X0012 ‐ ‐ ‐ ‐ ‐ ‐
‐continued‐
*Recommended spare parts
