Instruction Manual
D100399X012
EW Valve
July 2017
9
Figure 4. PTFE V‐Ring Packing Arrangements
UPPER WIPER
(KEY 12)
PACKING
FOLLOWER
(KEY 13)
WASHER
(KEY 10)
SPRING
(KEY 8)
PACKING BOX
RING (KEY 11)
FEMALE
ADAPTOR
PACKING RING
MALE
ADAPTOR
LOWER WIPER
FEMALE
ADAPTOR
PACKING RING
MALE
ADAPTOR
LOWER WIPER
UPPER WIPER
(KEY 12)
PACKING
FOLLOWER
(KEY 13)
SPACER
(KEY 8)
PACKING BOX
RING (KEY 11)
1
1
FOR S31600 (316 SST) OR
S17400 (17‐4PH SST)
METAL PACKING BOX PARTS
FOR ALL OTHER METAL PACKING
BOX PART MATERIALS
SINGLE ARRANGEMENTS
NOTE:
PACKING SET (KEY 6) (2 REQ'D FOR DOUBLE ARRANGEMENTS).
12A7837−A/IL
B2398
1
1
1
1
1
1
1
UPPER WIPER
(KEY 12)
PACKING
FOLLOWER (KEY 13)
LANTERN RING
(KEY 8)
PACKING BOX
RING (KEY 11)
MALE ADAPTOR
PACKING RING
FEMALE ADAPTOR
LOWER WIPER
ASSEMBLY 1
(POSITIVE
PRESSURES)
ASSEMBLY 2
(VACUUM)
ASSEMBLY 3
(POSITIVE
PRESSURES
& VACUUM)
ASSEMBLY 1
(POSITIVE
PRESSURES)
ASSEMBLY 2
(VACUUM)
ASSEMBLY 3
(POSITIVE
PRESSURES
& VACUUM)
ASSEMBLY 1
(POSITIVE
PRESSURES)
ASSEMBLY 2
(VACUUM)
ASSEMBLY 3
(POSITIVE
PRESSURES
& VACUUM)
9.5 mm (3/8 INCH) STEM 12.7 mm (1/2 INCH) STEM 19.1, 25.4, OR 31.8 mm
(3/4, 1, OR 1‐1/4 INCH) STEM
DOUBLE ARRANGEMENTS
12A8187-C 12A7814-C 12A7839-A
