Instruction Manual
D103175X012
GX Valve and Actuator
April 2011
26
Figure 10. Fisher GX Balanced Trim
(Standard for DN 80 and 100 [NPS 3 and 4])
GE07161‐D
APPLY LUBRICANT
Figure 11. Fisher GX Balanced Trim
(DN 150 [NPS 6])
GE17575‐C
APPLY LUBRICANT
Figure 12. Fisher GX Unbalanced Port‐Guided Trim
(DN 40 to 150 [NPS 1‐1/2 to 6])
GE03755_8
Figure 13. Fisher GX Whisper Trim™ III
(DN 150 [NPS 6])
GE23496‐A
APPLY LUBRICANT
