Emerson Fisher GX User Manual

Instruction Manual
D103175X012
GX Valve and Actuator
April 2011
27
Figure 14. Fisher GX Control Valve with Typical Soft
Seat Trim Construction
(Port Sizes of 36mm ‐ 136mm)
W9023‐1
2
3
Figure 15. Fisher GX PTFE Packing
DN15 through DN150 (NPS 1/2 through 6)
GE03755_14
Figure 16. Fisher GX Graphite ULF Packing
DN15 through DN100 (NPS 1/2 through 4)
GE11961_C
43
42
43
44
Figure 17. Fisher GX Graphite ULF Packing
DN150 Only (NPS 6 Only)
GE03755_23
43
42
43
44
