PACSystems™ RX3i and RSTi-EP CPU Reference Manual Section 6

GFK-2222AK October 2019

Serial I/O, SNP & RTU Protocols 158

6.2.15.1 Example Command Block for the Read String Function

Value

(decimal)

Value

(hexadecimal)

Meaning

Address

0005

Data block length

Address +1

0000

NOWAIT mode

Address +2

0008

Status word memory type (%R)

Address +3

0000

Status word address minus 1

(%R0001)

Address +4

0000

Not used

Address +5

0000

Not used

Address +6

4403

1133

Read string command

Address +7

0030

001E

Read time-out (30 seconds)

Address +8

0013

000D

Terminating character (carriage

return): must be between 0 and

255 (0xFF), inclusive

Address +9

0008

Input data memory type (%R)

Address +10

0100

0064

Input data memory address

(%R0100)
