Property Damage: Do not connect the electrical
power until the tank is full of water. Failure to
comply will burn out the heating elements.
6
2
■■ Ensure wall or cabinet is strong
enough to hold the weight of a full
heater. The model W152 tank holds
2-1/2 gallons and weights 34 lbs.
when full.
Continue with “Step C” if wall mounting.
■■ Hold tank in the position to be
mounted and mark with a pencil
the top and center for the tank on the
wall (mount to wall stud or
added 2x4).
■■ Measure down 1-1/2" and mount the
metal mounting bracket using two
screws provided.
■■ Hang the water heater from the
mounting bracket using the two slots
in the back of the tank jacket.
The W152 model is designed for wall or
floor mounting.
■■ Select a spot to mount water heater
vertically, with water connection at
the top.
■■ Water heater must be located within
3-1/2 ft. of a grounded 120-volt
electrical outlet.
B
C
