Distribution Cabinet Dimensions—List GA
NOTES :
1.
2. Weight (In Pounds).
3.
Finish :
All dimensions are in inches.
Body: Bright Zinc
Front Panel: Textured Cool
Gray (M500-146)
Net: 15
Shipping: 19
MOUNTING ANGLE DETAIL
0.250 x 0.375
SLOT
(2 PLACES)
1.250
0.234
0.234
0.703
0.251
0.251
0.734
(3) 0.281 DIA.
TOP VIEW
FRONT VIEW
1.718
19.000
17.380
18.250
LEFT SIDE VIEW
RIGHT SIDE VIEW
23.000
22.250
12.000
5.000
See Mounting Angle Detail
To Next Page
