92 Chapter 6 Use Of Monitoring Module M501D
No. Alarm name Alarm description
Default
alarm
level
Default
associated
relay
Associated
setting parameters
4 Battery protect
During the discharge of the battery, when the
battery voltage is lower than the set value of the
‘battery protection’ parameter or the discharge
time exceeds the set value of the ‘ LVD2
protection time’ parameter, the battery protection
contactor will be automatically disconnected.
Manual control of battery LVD
Critical
alarm
4
Battery LVD
enabled
5
Battery charge
over-current
The charging current of battery pack 1 is larger
than the set value of the parameter ‘charging
over-current threshold’.
Observati
on alarm
N/A
Battery charge
over-current
6
Battery bypass
disconnected
Overload, short circuit, manual disconnection or
alarm circuit error
Critical
alarm
N/A
7
monitoring
module fault
Hardware self-detection error No alarm N/A
monitoring module
fault
8
Manual
management
of module
The monitoring battery management is in manual
state
No alarm N/A
9
Battery non-
float charge
state
Including: auto boost charge, cyclic boost charge,
constant current test, fast test
No alarm 7
Battery non-float
charge state
10
Battery
discharge
Battery is discharging. No alarm N/A
11
System
current
unbalanced
In the system with shunt, there exists great
difference between the collected load current plus
the battery current and the module output
current.
No alarm N/A
12
Fast test
abnormal
During the fast test, the discharge capacity of two
batteries is larger than the set value
Observati
on alarm
N/A
13
Battery test
abnormal
The battery discharge time is shorter than the
estimated time
Observati
on alarm
N/A
14
Output voltage
abnormal
The control output voltage is different from the
collected bus voltage, and different from the
reported data of the module. The error is larger
than 1V
Observati
on alarm
N/A
15 AC power-cut
In the system with AC collection board:
All the AC voltages are lower than 80V.
Neither AC circuit 1 nor circuit 2 is in working
state.
In the system without AC collection board:
The AC input of all the rectifiers is cut off.
The AC input voltage of all the rectifiers is lower
than the ‘phase loss alarm’ threshold
Critical
alarm
1 AC power-cut
16
Multi-module
fault
More than 2 rectifiers have alarm
Critical
alarm
N/A
17
System
maintenance
time out
It has exceeded the set maintenance time of the
system
Observati
on alarm
N/A
18
Module
communicatio
n interrupted
The rectifier fails to communicate with the
monitoring unit
Critical
alarm
3
19
Module AC
power cut
All the AC voltages are lower than the under-
voltage threshold
Critical
alarm
3
20
Module over-
temperature
The internal temperature of the module is too
high, higher than 90°C
Observati
on alarm
N/A
21 Module fault
The rectifier voltage is too high, higher than upper
limit of the rectifier voltage
Critical
alarm
3
22
Module
protection
AC over-voltage (295V) or under-voltage (80V)
Observati
on alarm
3
23
Module fan
fault
The fan has fault, and the temperature of the
rectifier air inlet is high
Critical
alarm
3
24
Module limited
power
The AC voltage is low, and the internal
temperature or air inlet temperature of the
rectifier is high
Observati
on alarm
3
