Emerson Packaged Drives and Engineered Systems - Page 6

323
www.emersonct.com
800-533-0031
AC RapidPak
Normal Duty 460 VAC, 3-Phase Input and Output, 50/60 Hz Input
Normal Duty
110% for 1 minute
Slim Enclosure Cube Enclosure
Order Code
Dimensions
HxWxD (in)
Weight
(Ibs)
Order Code
Dimensions
HxWxD (in)
Weight
(Ibs)
HP Amps
1.5 2.8 RSxxN41P5xxx-x 38x16x16 135 RCxxN41P5xxx-x 24x16x16 70
2 3.8 RSxxN4002xxx-x 38x16x16 135 RCxxN4002xxx-x 24x16x16 70
3 5 RSxxN4003xxx-x 38x16x16 135 RCxxN4003xxx-x 24x16x16 70
5 8.8 RSxxN4005xxx-x 38x16x16 135 RCxxN4005xxx-x 24x16x16 70
7.5 11 RSxxN47P5xxx-x 38x16x16 135 RCxxN47P5xxx-x 24x16x16 70
10 15.3 RSxxN4010xxx-x 38x16x16 140 RCxxN4010xxx-x 24x16x16 70
15 21 RSxxN4015xxx-x 38x16x16 140 RCxxN4015xxx-x 24x16x16 70
20 29 RSxxN4020xxx-x 38x16x16 140 RCxxN4020xxx-x 24x16x16 70
25 35 RSxxN4025xxx-x 56x16x16 140 RCxxN4025xxx-x 30x24x16 150
30 43 RSxxN4030xxx-x 56x16x16 210 RCxxN4030xxx-x 30x24x16 150
40 56 RSxxN4040xxx-x 56x16x16 210 RCxxN4040xxx-x 30x24x16 250
50 68 RSxxN4050xxx-x 72x21x16 300 RCxxN4050xxx-x 39x30x16 280
60 83 RSxxN4060xxx-x 72x21x16 350 RCxxN4060xxx-x 39x30x16 280
75 104 RSxxN4075xxx-x 72x21x16 350 RCxxN4075xxx-x 39x30x16 280
100 138 RSxxN4100xxx-x 72x36x18 550
n/a
125 168 RSxxN4125xxx-x 72x36x18 550
150 202 RSxxN4150xxx-x 90x36x20 700
200 236 RSxxN4200xxx-x 90x36x20 700
Order string: The base Order Code requires a minimum of 12 characters in sequence to create the order string.
Heavy Duty 230 VAC, 3-Phase Input and Output, 50/60 Hz Input
Heavy Duty
150% for 1 minute
Slim Enclosure Cube Enclosure
Order Code
Dimensions
HxWxD (in)
Weight
(Ibs)
Order Code
Dimensions
HxWxD (in)
Weight
(Ibs)
HP Amps
1 4.3 RSxxH2001xxx-x 38x16x16 135 RCxxH2001xxx-x 24x16x16 65
1.5 5.8 RSxxH21P5xxx-x 38x16x16 135 RCxxH21P5xxx-x 24x16x16 65
2 7.5 RSxxH2002xxx-x 38x16x16 135 RCxxH2002xxx-x 24x16x16 65
3 10.6 RSxxH2003xxx-x 38x16x16 140 RCxxH2003xxx-x 24x16x16 70
5 17 RSxxH2005xxx-x 38x16x16 140 RCxxH2005xxx-x 24x16x16 70
7.5 25 RSxxH27P5xxx-x 38x16x16 140 RCxxH27P5xxx-x 24x16x16 70
10 31 RSxxH2010xxx-x 56x16x16 140 RCxxH2010xxx-x 30x24x16 70
15 42 RSxxH2015xxx-x 56x16x16 210 RCxxH2015xxx-x 30x24x16 145
20 56 RSxxH2020xxx-x 72x21x16 210 RCxxH2020xxx-x 39x30x16 145
25 68 RSxxH2025xxx-x 72x21x16 300 RCxxH2025xxx-x 39x30x16 200
30 80 RSxxH2030xxx-x 72x21x16 300 RCxxH2030xxx-x 39x30x16 200
Note: Weight does not include options.
