AC RapidPak
AC RapidPak Order Code Configurator
Enclosure Style
S = Slimline
2
C = Cube
1
Voltage Rating
8 = 208 V / 3 / 60
2 = 230 V / 3 / 60
3 = 380 V / 3 / 60
4 = 460 V / 3 / 60
Additional Options (if required)
1 = AC Input Reactor
2 = AC Output Reactor
4 = Auto 3-Contactor Bypass
5 = Blower Motor Starter
A = Manual Three-Contactor Bypass
F = NEMA-3R Enclosure
Input Power
0 = Main Lugs with Input Fusing
1 = Thru-Door Disconnect C/B
2 = Thru-Door Disconnect Switch
Product
R = RapidPak
Drive Model
SKN = SK Normal Duty
SKH = SK Heavy Duty
CGN = GP20 Normal Duty
CGH = GP20 Heavy Duty
SPN = SP Normal Duty
SPH = SP Heavy Duty
Horsepower
see Order Code tables
Keypad
N = Keypad on Drive
K = Keypad on Door
Door Mounted Operator Station
3
0 = Blank
1 = Stop PB, Start PB, Fault Light, Pot
2 = #1 + JOG PB, Fwd/Rev SS
3 = #2 + Power On Light
4 = HOA SS, Power On, VFD Run, Fault Light, Pot
5 = HOA SS plus Bypass
1 Cube Enclosure Style does not allow for additional options (insufficient space)
2 Smallest Slimline Enclosure Style allows all the options unless bypass is selected,
then there is a limit of either an input or output reactor.
3 Abbreviation Key: PB = Push button; SS = Selector Switch; HOA = Hand-Off-Auto
Order String
R x xxx x xxx x x x - xxxxx
Order string: The base Order Code requires a minimum of 12 characters in sequence to create the order string.
For options not included in the Order Code configurator, please consult factory.
Additional Order Code
AC Input Reactor 3% impedance input line reactor. Reduces harmonics to line. Slimline only
AC Output Reactor 3% impedance output line reactor. Increases motor insulation life by reducing dV/dt. Slimline only
Auto Three-Contactor Bypass Used in applications where full speed operation is required if drive becomes inoperable. Automatically switches
upon drive fault. Requires Operator Station #5. Slimline only
Blower Motor Starter Controls separately powered motor blower on TEBC and DPFV motors used for wide speed range applications.
Not available with Bypass Options. Slimline only
Manual Three-Contactor Bypass Used in applications where full speed operation is required if drive becomes inoperable. Manual (operator)
activated via Operator Station #5. Slimline only
Nema 3R Enclosure Enclosure intended for outdoor use. Provides a degree of protection against falling rain, sleet, and external ice.
