Emerson QuickPanel+ IC755C S12CD Series - Ethernet Port Details

Quick Start Guide Section 4
GFK-2893P Sep 2019
Mounting & Installation 28
4.6 Connectors
4.6.1 Power Connector Details
Pin #
Signal Name
Pin-out
1
+24 V dc
†
2
GND
3
FG
†
IC755CxSxxCDA supports both +12 V dc or +24 V dc IN
4.6.2 Ethernet Port Details
Interface: Ethernet 10BASE-T/100BASE-TX
Pin #
Signal Name
Pin-out
1
TX+
2
TX-
3
RX+
4
NC
5
NC
6
RX-
7
NC
8
NC
4.6.3 USB Host Port Details
Interface: 2x USB 2.0
Pin #
Signal Name
Pin-out
1
USB_VCC
5.
2
USB_D-
3
USB_D+
4
USB_GND
