Emerson SC319C User Manual

2-4-5 U25NDA
Pin of [12]
Pin of [10]
Grooves of [28]
[28]
When reassembling [10] and
[12], confirm that pin of [10]
and pin of [12] are in the
grooves of [28] as shown.
[11]
[13]
[12]
A
[10]
(L-1)
(P-3)
Adj. Screw
(P-2)
(L-2)
View for A
Fig. DM8
[14]
[15]
(S-9)
(S-8)
Fig. DM9
[17]
[16]
[18]
(S-10)
(L-3)
After removing the Screw (S-10),
while pressing the Locking Tab
(L-3), remove [16].
Fig. DM10
[8]
[8]
[9]
(S-7)
(S-6)
LDG
Belt
A
View for A
Fig. DM7
Desolder
from bottom
Lead with White Stripe
