Emerson SC319C User Manual

20020205 3-2-1 T7300CA
MECHANICAL PARTS LIST
PRODUCT SAFETY NOTE: Products marked with a
# have special characteristics important to safety.
Before replacing any of these components, read care-
fully the product safety notice in this service manual.
Don't degrade the safety of the product through
improper servicing.
NOTES:
1. Parts that are not assigned part numbers (---------)
are not available.
2. Comparison Chart of Models and Marks
Model Mark
SC319C A
6319CC B
EWC1902 C
Ref. No. Mark Description Part No.
A1X A FRONT CABINET ASSEMBLY T7300UA 0EM101149
A1X B FRONT CABINET ASSEMBLY T7302UC 0EM101166
A1X C FRONT CABINET ASSEMBLY T7303UD 0EM101161
A1-1 A FRONT CABINET T7300UA 0EM000616
A1-1 B FRONT CABINET T7302UC 0EM000618
A1-1 C FRONT CABINET T7303UD 0EM000609
A1-2 A CONTROL PLATE T7300UA 0EM201557
A1-2 B CONTROL PLATE T7302UC 0EM201567
A1-2 C CONTROL PLATE T7303UD 0EM201568
A1-3 A BRAND PLATE T5300UA:SYMPHONIC 0EM406823
A1-3 B BRAND PLATE T5302UC:SYLVANIA 0EM406914
A1-3 C BRAND PLATE T5303UDEMERSON 0EM406919
A1-4 A CASSETTE DOOR T5300UA 0EM301569
A1-4 B,C CASSETTE DOOR T5303UD 0EM406915
A1-5 DOOR SPRING B5000UA or 0VM403773
DOOR SPRING(Z10) T5200UA 0EM406687
A1-6 CLOTH(4X7XT0.7) T5000UA 0EM404974
A2 REAR CABINET T7303UD 0EM000614
A3# A RATING LABEL T7300UA ----------
A3# B RATING LABEL T7302UC ----------
A3# C RATING LABEL T7303UD ----------
A4 A POP LABEL T5000UA 0EM404722
A4 B POP LABEL T5302UC 0EM406962
A4 C POP LABEL T5303UD 0EM406966
1B1 DECK ASSEMBLY CZD011/VM1426 N1426FT
B1 TENSION SPRING B0080B0:EM40808 26WH006
B2 CRT MOUNTING SCREW
B0030U1:K42419
8A00083
B3 SHIELD PLATE (Z11 13V) T5300UA 0EM406843
B4# DEGAUSS HOLDER L9800UA 0EM404845
B5 CLOTH 190X15XT0.5 TS7623
B11 CLOTH(10X30XT0.5) B5900UA 0EM404486
CL802 WIRE ASSEMBLY 2P/150 WX1B5900-001
CLN551
#
CRT WIRE WX1T7000-005 WX1T7000-005
DG601# DEGAUSSING COIL F-020 or LLBH00ZTM020
# DEGAUSSING COIL AVDG015 LLBH00ZWR015
L1 SCREW, P-TIGHT 4X18 BIND HEAD + GBMP4180
L4 SCREW, ASSEMBLED 12:M3X14 0EM404416
SP801 SPEAKER S08F02B or DSD0808XQ010
SPEAKER J-F097-C5 DSD0808DCP01
TB1 TRAY CHASSIS T5300UA 0EM000588
TB2 TOP SHIELD T5300UA 0EM301573
TB10 RCA HOLDER T5300UA 0EM406869
TB22# 19V CHASSIS NO. LABEL TJ T7300UA 0EM406881
TB23 TRAY COVER TD250UA 0EM406459
TL1 SCREW, P-TIGHT 3X12 WASHER HEAD+ GCMP3120
TL3 SCREW, S-TIGHT 3X4 BIND HEAD+ GBMS3040
TL13 SCREW, B-TIGHT M3X8 BIND HEAD+ GBMB3080
TL14 SCREW, B-TIGHT M3X8 BIND HEAD+ GBMB3080
TL15 SCREW TAPPING M4X14 DBU14140
TL16 SCREW, P-TIGHT 3X10 BIND HEAD+ GBMP3100
TL17 SCREW, P-TIGHT M3X10 WASHER
HEAD+
GCMP3100
PACKING
S1 A CARTON T7300UA 0EM301574
S1 B CARTON T7302UC 0EM407007
S1 C CARTON T7303UD 0EM406960
S2 STYROFOAM TOP ASSEMBLY T7300UA 0EM406850
S3 STYROFOAM BOTTOM ASSEMBLY
T7300UA
0EM406851
S4 A SERIAL NO. LABEL T7300UA 0EM406853
S4 B SERIAL NO. LABEL T7302UC 0EM407009
S4 C SERIAL NO. LABEL T7303UD 0EM406974
S6 SET SHEET B7500UA:1000X1700 0EM402178
S14 TVCR HOLD PAD T7300UA 0EM406849
ACCESSORIES
X1 POLYETHYLENE BAG B5310UL Z223380
X2# A OWNER'S MANUAL T5300UA 0EMN01882
X2# B OWNER'S MANUAL T5302UC 0EMN01893
X2# C OWNER'S MANUAL T5303UD 0EMN01894
X3 A REMOCON UNIT 512/ERC001/N0150UD
or
N0150UD
A REMOCON UNIT 512/ERC001/N0107UD N0107UD
X3 B REMOCON UNIT 512/ERC001/N0151UD N0151UD
X3 C REMOCON UNIT 512/ERC001/N0162UD
or
N0162UD
C REMOCON UNIT 512/ERC001/N0159UD N0159UD
X4 DRY BATTERY R6P UM3 or XB0M451GH001
DRY BATTERY R6P(AR)2PX or XB0M451HU002
DRY BATTERY R6P(AR)2P X ICI or XB0M451HU003
DRY BATTERY(SUNRISE) R6SSE/2S or XB0M451MS002
DRY BATTERY R6P/2S XB0M451T0001
X7 A RETURN STOP SHEET L6100UA 0EM407076
X7 B RETURN STOP SHEET L6101UB 0EM407077
X7 C RETURN STOP SHEET T4259UK 0EM406203A
Note:
A number of different CRTs (V501) may be used in these models, Each CRT is used in
combination with a specific deflection yoke (L551). Refer to Table 1 and the following
parts list for details.
CRT TYPE A
L551# DEFLECTION YOKE LLBY00ZSY006 LLBY00ZSY006
V501# CRT A48JLL90X TCRT190QS009
V501-1 C.P.MAGNET JH225-014 XM04000BV009
V501-2 WEDGE FT-00110W XV10000T4001
V501-3 RUBBER MAGNET 20X10X1.2 XM05000BV001
CRT TYPE B
L551# DEFLECTION YOKE CDY-M2019F LLBY00ZQS004
Ref. No. Mark Description Part No.
