20020205 3-2-2 T7300CA
Table 1 (V501 and L551 Combination)
Note 1: Purity and Convergence Adjustments must be
performed following CRT replacement. Refer to Electri-
cal Adjustment Instructions.
Note2: Please confirm CRT Type No. on the CRT
Warning Label which is located on the CRT. Then See
the Table 1 for V501 and L551 combination chart.
Please refer this CRT, Deflection Yoke combination
chart for parts order.
CRT Warning Label Location
V501# CRT A48JLL90X TCRT190QS009
V501-1 C.P.MAGNET JH225-014 XM04000BV009
V501-2 WEDGE FT-00110W XV10000T4001
V501-3 RUBBER MAGNET 20X10X1.2 XM05000BV001
CRT TYPE C
L551# DEFLECTION YOKE LLBY00ZSY007 LLBY00ZSY007
V501# CRT A48LRH93X(W) TCRT190P7002
V501-1 C.P.MAGNET JH225-014 XM04000BV009
V501-2 WEDGE FT-00110W XV10000T4001
V501-3 RUBBER MAGNET 20X10X1.2 XM05000BV001
CRT TYPE D
L551# DEFLECTION YOKE CDY-M2023F LLBY00ZQS005
V501# CRT A48LRH93X(W) TCRT190P7002
V501-1 C.P.MAGNET JH225-014 XM04000BV009
V501-2 WEDGE FT-00110W XV10000T4001
V501-3 RUBBER MAGNET 20X10X1.2 XM05000BV001
CRT TYPE E
L551# DEFLECTION YOKE 330P510A37 LLBY00ZTHA01
V501# CRT A48LGS30X TCRT190THA01
V501-1 C.P.MAGNET JH225-014 XM04000BV009
V501-2 WEDGE FT-00110W XV10000T4001
V501-3 RUBBER MAGNET 20X10X1.2 XM05000BV001
CRT TYPE F
L551# DEFLECTION YOKE LLBY00ZSY008 LLBY00ZSY008
V501# CRT A48LVL095X TCRT190MS011
V501-1 C.P.MAGNET JH225-014 XM04000BV009
V501-2 WEDGE FT-00110W XV10000T4001
V501-3 RUBBER MAGNET 20X10X1.2 XM05000BV001
CRT TYPE G
L551# DEFLECTION YOKE KDY3MDD18X LLBY00ZMS019
V501# CRT A48LVL095X TCRT190MS011
V501-1 C.P.MAGNET JH225-014 XM04000BV009
V501-2 WEDGE FT-00110W XV10000T4001
V501-3 RUBBER MAGNET 20X10X1.2 XM05000BV001
CRT TYPE H
L551# DEFLECTION YOKE KDY3MDD74X LLBY00ZMS024
V501# CRT A48AKH13X01 K or TCRT190CP043
# CRT:MINI BARE CHUNGHWA T7300UA or 0EDM06903
# CRT A48AKH13X TCRT190CP044
V501-1 C.P.MAGNET JH225-014 XM04000BV009
V501-2 WEDGE FT-00110W XV10000T4001
V501-3 RUBBER MAGNET 20X10X1.2 XM05000BV001
V501: CRT Type No. V501: CRT Part No.
L551: Deflection
Yoke Part No.
CRT A48JLL90X TCRT190QS009 LLBY00ZSY006
CRT A48JLL90X TCRT190QS009 LLBY00ZQS004
Ref. No. Mark Description Part No.
CRT A48LRH93X(W) TCRT190P7002 LLBY00ZSY007
CRT A48LRH93X(W) TCRT190P7002 LLBY00ZQS005
CRT A48LGS30X TCRT190THA01 LLBY00ZTHA01
CRT A48LVL095X TCRT190MS011 LLBY00ZSY008
CRT A48LVL095X TCRT190MS011 LLBY00ZMS019
CRT A48AKH13X01 K TCRT190CP043
LLBY00ZMS024
CRT:MINI BARE
CHUNGHWA T7300UA
0EDM06903
CRT A48AKH13X TCRT190CP044
V501: CRT Type No. V501: CRT Part No.
L551: Deflection
Yoke Part No.
CRT
CRT Warning Label
CRT Type No.
