Emerson SC319C User Manual

20020205 3-3-4 T7300EL
D312 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
SWITCHING DIODE 1N4148 NDTZ001N4148
D313 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
SWITCHING DIODE 1N4148 NDTZ001N4148
D314 ZENER DIODE MTZJT-779.1B or QDTB0MTZJ9R1
ZENER DIODE DZ-9.1BSBT265 NDTB0DZ9R1BS
D401 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
SWITCHING DIODE 1N4148 NDTZ001N4148
D552 DIODE 1N5397-B or NDLZ001N5397
RECTIFIER DIODE ERB12-06 QDQZ0ERB1206
D571# DIODE FR154 or NDLZ000FR154
# FAST RECOVERY DIODE ERB44-02 QDPZ0ERB4402
D572# DIODE FR104-B or NDLZ000FR104
# RECTIFIER DIODE 10ELS2 or QDQZ0010ELS2
# RECTIFIER DIODE ERA22-02 QDPZ0ERA2202
D584# SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
# SWITCHING DIODE 1N4148 NDTZ001N4148
D585 ZENER DIODE MTZJT-775.1B or QDTB0MTZJ5R1
ZENER DIODE DZ-5.1BSBT265 NDTB0DZ5R1BS
D591# ZENER DIODE MTZJT-7736B or QDTB00MTZJ36
# ZENER DIODE DZ-36BSBT265 NDTB00DZ36BS
D593# PCB JUMPER D0.6-P5.0 JW5.0T
D595# ZENER DIODE MTZJT-7720B or QDTB00MTZJ20
# ZENER DIODE DZ-20BSBT265 NDTB00DZ20BS
D596# SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
# SWITCHING DIODE 1N4148 NDTZ001N4148
D597# SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
# SWITCHING DIODE 1N4148 NDTZ001N4148
D598# DIODE FR104-B or NDLZ000FR104
# RECTIFIER DIODE 10ELS2 or QDQZ0010ELS2
# RECTIFIER DIODE ERA22-02 QDPZ0ERA2202
D601 PCB JUMPER D0.6-P10.0 JW10.0T
D603# DIODE 1N5397-B or NDLZ001N5397
# RECTIFIER DIODE ERB12-06 QDQZ0ERB1206
D604# DIODE 1N5397-B or NDLZ001N5397
# RECTIFIER DIODE ERB12-06 QDQZ0ERB1206
D605# DIODE 1N5397-B or NDLZ001N5397
# RECTIFIER DIODE ERB12-06 QDQZ0ERB1206
D606# DIODE 1N5397-B or NDLZ001N5397
# RECTIFIER DIODE ERB12-06 QDQZ0ERB1206
D607# ZENER DIODE MTZJT-7724C or QDTC00MTZJ24
# ZENER DIODE DZ-24BSCT265 NDTC00DZ24BS
D608 ZENER DIODE MTZJT-7736A or QDTA00MTZJ36
ZENER DIODE DZ-36BSAT265 NDTA00DZ36BS
D609# SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
# SWITCHING DIODE 1N4148 NDTZ001N4148
D610 ZENER DIODE MTZJT-775.6B or QDTB0MTZJ5R6
ZENER DIODE DZ-5.6BSBT265 NDTB0DZ5R6BS
D611 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
SWITCHING DIODE 1N4148 NDTZ001N4148
D613# RECOVERY DIODE ERC18-04 QDZZ0ERC1804
D614# DIODE FR104-B or NDLZ000FR104
# RECTIFIER DIODE 10ELS2 or QDQZ0010ELS2
# RECTIFIER DIODE ERA22-02 QDPZ0ERA2202
D615# DIODE 1ZC33 or QDQZ0001ZC33
# ZENER DIODE RD33FB QDQZ000RD33F
D616# SCHOTTKY BARRIER DIODE 21DQ04 or QDQZ0021DQ04
# SCHOTTKY BARRIER DIODE ERB81-004 AERB81004***
D617# SCHOTTKY BARRIER DIODE 11EQS04 or QD4Z011EQS04
# SCHOTTKY BARRIER DIODE ERA81-004 QDPZERA81004
D618# SCHOTTKY BARRIER DIODE 11EQS04 or QD4Z011EQS04
Ref. No. Description Part No.
# SCHOTTKY BARRIER DIODE ERA81-004 QDPZERA81004
D619 DIODE FR104-B or NDLZ000FR104
RECTIFIER DIODE 10ELS2 or QDQZ0010ELS2
RECTIFIER DIODE ERA22-02 QDPZ0ERA2202
D620# ZENER DIODE MTZJT-776.8B or QDTB0MTZJ6R8
# ZENER DIODE DZ-6.8BSBT265 NDTB0DZ6R8BS
D621# SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
# SWITCHING DIODE 1N4148 NDTZ001N4148
D622# SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
# SWITCHING DIODE 1N4148 NDTZ001N4148
D623# SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
# SWITCHING DIODE 1N4148 NDTZ001N4148
D626 ZENER DIODE MTZJT-7736A or QDTA00MTZJ36
ZENER DIODE DZ-36BSAT265 NDTA00DZ36BS
D627# ZENER DIODE MTZJT-7715A or QDTA00MTZJ15
# ZENER DIODE DZ-15BSAT265 NDTA00DZ15BS
D628# SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
# SWITCHING DIODE 1N4148 NDTZ001N4148
D629 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
SWITCHING DIODE 1N4148 NDTZ001N4148
D630# PCB JUMPER D0.6-P5.0 JW5.0T
D631 ZENER DIODE MTZJT-776.8A or QDTA0MTZJ6R8
ZENER DIODE DZ-6.8BSAT265 NDTA0DZ6R8BS
D632 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
SWITCHING DIODE 1N4148 NDTZ001N4148
D633 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
SWITCHING DIODE 1N4148 NDTZ001N4148
D634 ZENER DIODE MTZJT-778.2B or QDTB0MTZJ8R2
ZENER DIODE DZ-8.2BSBT265 NDTB0DZ8R2BS
D635 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
SWITCHING DIODE 1N4148 NDTZ001N4148
D636 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
SWITCHING DIODE 1N4148 NDTZ001N4148
D638# SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
# SWITCHING DIODE 1N4148 NDTZ001N4148
D640# SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
# SWITCHING DIODE 1N4148 NDTZ001N4148
D641# ZENER DIODE MTZJT-7736A or QDTA00MTZJ36
# ZENER DIODE DZ-36BSAT265 NDTA00DZ36BS
D646 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
SWITCHING DIODE 1N4148 NDTZ001N4148
D647 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
SWITCHING DIODE 1N4148 NDTZ001N4148
D648 SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
SWITCHING DIODE 1N4148 NDTZ001N4148
D649# SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
# SWITCHING DIODE 1N4148 NDTZ001N4148
D801# SWITCHING DIODE 1SS133(T-77) or QDTZ001SS133
# SWITCHING DIODE 1N4148 NDTZ001N4148
ICS
IC201# MICROCONTROLLER 16BIT M37760M8H8C8GP QSZAB0RMB095
IC202 IC:MEMORY BR24C02F-W or QSMBA0SRM003
IC:MEMORY AT24C02N-10SC or NSMMA0SAZ012
IC(EEPROM) M24C02-MN6 or NSMMA0SSS028
IC:MEMORY BR24C02F QSMMA0SRM003
IC301# IC:CHROMA/IF 1 CHIP M61210FP-R60* or QSZAA0RMB086
# IC:CHROMA/IF 1 CHIP M61210FP-R61 or QSZAB0RMB086
# IC:CHROMA/IF 1 CHIP M61210FP-R62* QSZAC0RMB086
IC401 IC:Y/C/A LA71091M QSZBA0RSY012
IC551# VERTICAL OUTPUT IC AN5522 or QSZBA0SMS002
Ref. No. Description Part No.
