Emerson SC319C User Manual

20020205 3-3-5 T7300EL
# VERTICAL OUTPUT IC LA78040A QSBBA0SSY003
IC601# PHOTOCOUPLER LTV-817B-F or NPEB0LTV817F
# PHOTOCOUPLER LTV-817C-F or NPEC0LTV817F
# PHOTO COUPLER PC817X6 QPE600PC817X
IC602# VOLTAGE REGULATOR KIA7805API or NSBBA0SJY011
# VOLTAGE REGULATOR KA7805A or NSZBA0SF3052
# IC:VOLTAGE REGULATOR AN7805F AN7805F
IC801 AUDIO AMP LA4224 QSZAA0SSY005
COILS
L001 PCB JUMPER D0.6-P5.0 JW5.0T
L211# CHOKE COIL 47µH-K LLBD00PKV007
L301 PCB JUMPER D0.6-P5.0 JW5.0T
L302 INDUCTOR 15µH-J-26T or LLAXJATTU150
INDUCTOR 15µH-K-26T LLAXKDTKA150
L303 INDUCTOR 12µH-J-26T or LLAXJATTU120
INDUCTOR 12µH-K-26T LLAXKDTKA120
L305 INDUCTOR 1.0µH-J-26T or LLAXJATTU1R0
INDUCTOR 1.0µH-K-26T LLAXKDTKA1R0
L306 PCB JUMPER D0.6-P5.0 JW5.0T
L402 INDUCTOR 22µH-J-26T or LLAXJATTU220
INDUCTOR 22µH-K-26T LLAXKDTKA220
L404 CHOKE COIL 47µH-K LLBD00PKV007
L505 CHOKE COIL 47µH-K LLBD00PKV007
L601# LINE FILTER SA-91213B or LLBG00ZSA002
# LINE FILTER TLF12UA302W1R0 or LLBG00ZTU025
# LINE FILTER 5.0MH 6Y075 or LLBG00ZKT004
# LINE FILTER UU10.5-A or LLBG00ZY2008
# LINE FILTER TLF14CB3321R0 or LLBG00ZTU012
# LINE FILTER 6.35MH UU10-002 LLBG00ZKV001
L872 INDUCTOR 47µH-K-5FT or LLARKBSTU470
INDUCTOR 47µH-K-5FT LLARKDSKA470
TRANSISTORS
Q205 TRANSISTOR 2SC2785(F) or QQSF02SC2785
TRANSISTOR 2SC2785(H) or QQSH02SC2785
TRANSISTOR 2SC2785(J) or QQSJ02SC2785
TRANSISTOR KTC3199(GR) or NQS10KTC3199
TRANSISTOR KTC3198(GR) or NQS40KTC3198
TRANSISTOR 2SC1815-GR(TPE2) QQS102SC1815
Q206 PHOTO TRANSISTOR PT204-6B-12 or NPWZT2046B12
PHOTO TRANSISTOR MID-32A22 NPWZM1D32A22
Q301 TRANSISTOR 2SC2785(F) or QQSF02SC2785
TRANSISTOR 2SC2785(H) or QQSH02SC2785
TRANSISTOR 2SC2785(J) or QQSJ02SC2785
TRANSISTOR KTC3199(GR) or NQS10KTC3199
TRANSISTOR KTC3198(GR) or NQS40KTC3198
TRANSISTOR 2SC1815-GR(TPE2) QQS102SC1815
Q302 TRANSISTOR 2SC2785(F) or QQSF02SC2785
TRANSISTOR 2SC2785(H) or QQSH02SC2785
TRANSISTOR 2SC2785(J) or QQSJ02SC2785
TRANSISTOR KTC3199(GR) or NQS10KTC3199
TRANSISTOR KTC3198(GR) or NQS40KTC3198
TRANSISTOR 2SC1815-GR(TPE2) QQS102SC1815
Q401 TRANSISTOR 2SA1175(F) or QQSF02SA1175
TRANSISTOR KTA1267(GR) or NQS10KTA1267
TRANSISTOR KTA1266(GR) or NQS40KTA1266
TRANSISTOR 2SA1015-GR(TPE2) QQS102SA1015
Q402 TRANSISTOR 2SA1175(F) or QQSF02SA1175
TRANSISTOR KTA1267(GR) or NQS10KTA1267
TRANSISTOR KTA1266(GR) or NQS40KTA1266
TRANSISTOR 2SA1015-GR(TPE2) QQS102SA1015
Ref. No. Description Part No.
Q491 TRANSISTOR 2SC2785(F) or QQSF02SC2785
TRANSISTOR 2SC2785(H) or QQSH02SC2785
TRANSISTOR 2SC2785(J) or QQSJ02SC2785
TRANSISTOR KTC3199(GR) or NQS10KTC3199
TRANSISTOR KTC3198(GR) or NQS40KTC3198
TRANSISTOR 2SC1815-GR(TPE2) QQS102SC1815
Q571# TRANSISTOR 2SD2627LS-FEC-YB11 QQZZ02SD2627
Q572 TRANSISTOR 2SC1627Y-TPE2 QQSY02SC1627
Q591# TRANSISTOR 2SC2785(F) or QQSF02SC2785
# TRANSISTOR 2SC2785(H) or QQSH02SC2785
# TRANSISTOR 2SC2785(J) or QQSJ02SC2785
# TRANSISTOR KTC3199(GR) or NQS10KTC3199
# TRANSISTOR KTC3198(GR) or NQS40KTC3198
# TRANSISTOR 2SC1815-GR(TPE2) QQS102SC1815
Q601# MOS FET 2SK2662 QF5Z02SK2662
Q602# TRANSISTOR 2SC2120-O-TPE2 or QQS002SC2120
# TRANSISTOR 2SC2120-Y(TPE2) QQSY02SC2120
Q604# TRANSISTOR 2SC2785(F) or QQSF02SC2785
# TRANSISTOR 2SC2785(H) or QQSH02SC2785
# TRANSISTOR 2SC2785(J) or QQSJ02SC2785
# TRANSISTOR 2SC1815-GR(TPE2) QQS102SC1815
Q605 TRANSISTOR 2SC2785(F) or QQSF02SC2785
TRANSISTOR 2SC2785(H) or QQSH02SC2785
TRANSISTOR 2SC2785(J) or QQSJ02SC2785
TRANSISTOR KTC3199(GR) or NQS10KTC3199
TRANSISTOR KTC3198(GR) or NQS40KTC3198
TRANSISTOR 2SC1815-GR(TPE2) QQS102SC1815
Q606# TRANSISTOR 2SA950(O) or Q2SA9500TPE2
# TRANSISTOR 2SA950(Y) or Q2SA950YTPE2
# TRANSISTOR KTA1271(Y) NQSY0KTA1271
Q607 TRANSISTOR 2SC2785(F) or QQSF02SC2785
TRANSISTOR 2SC2785(H) or QQSH02SC2785
TRANSISTOR 2SC2785(J) or QQSJ02SC2785
TRANSISTOR KTC3199(GR) or NQS10KTC3199
TRANSISTOR KTC3198(GR) or NQS40KTC3198
TRANSISTOR 2SC1815-GR(TPE2) QQS102SC1815
Q608# TRANSISTOR 2SC2120-O-TPE2 or QQS002SC2120
# TRANSISTOR 2SC2120-Y(TPE2) or QQSY02SC2120
# TRANSISTOR KTC3203(Y) NQSY0KTC3203
Q609 TRANSISTOR 2SC2120-O-TPE2 or QQS002SC2120
TRANSISTOR 2SC2120-Y(TPE2) or QQSY02SC2120
TRANSISTOR KTC3203(Y) NQSY0KTC3203
Q610# TRANSISTOR 2SC2785(F) or QQSF02SC2785
# TRANSISTOR 2SC2785(H) or QQSH02SC2785
# TRANSISTOR 2SC2785(J) or QQSJ02SC2785
# TRANSISTOR KTC3199(GR) or NQS10KTC3199
# TRANSISTOR KTC3198(GR) or NQS40KTC3198
# TRANSISTOR 2SC1815-GR(TPE2) QQS102SC1815
Q611# TRANSISTOR 2SD400(F) QQUF002SD400
Q612 RES. BUILT-IN TRANSISTOR KRA103M or NQSZ0KRA103M
RES. BUILT-IN TRANSISTOR 2SA1346 or 2SA1346Z
RES. BUILT-IN TRANSISTOR BN1F4M-T QQSZ00BN1F4M
Q871 TRANSISTOR 2SA1175(F) or QQSF02SA1175
TRANSISTOR KTA1267(GR) or NQS10KTA1267
TRANSISTOR KTA1266(GR) or NQS40KTA1266
TRANSISTOR 2SA1015-GR(TPE2) QQS102SA1015
Q872 TRANSISTOR 2SC2120-O-TPE2 or QQS002SC2120
TRANSISTOR 2SC2120-Y(TPE2) or QQSY02SC2120
TRANSISTOR KTC3203(Y) NQSY0KTC3203
Q873 TRANSISTOR 2SC3331(T) or QSC3331TNPAA
TRANSISTOR 2SC3331(U) or QSC3331UNPAA
Ref. No. Description Part No.
