Operating Parameters/Special Conditions For Safe Use
Maximum Inlet Pressure:
3,500 psig / 241 bar / 24,132 kPa Standard
6,000 psig / 414 bar / 41368 kPa Optional
Maximum Outlet Pressure:
500 psig / 34 5 bar / 3,448 kPa
Outlet Pressure Ranges:
0-25, 0-50, 0-100, 0-250, 0-500 psig
0-17, 0-34, 0-69, 0-172, 0-345 bar
0-172, 0-345, 0-690, 0-1724, 0-3448 kPa
Design Proof Pressure
150% maximum rated
Leakage:
Internal: Bubble-tight
External: Designed to meet ≤ 2x10-8 atm cc/sec He
Voltage:
100 - 240 VAC, 50/60 Hz, 400W at 240VAC, 100W at 120VAC
Full Load Amps:
2.0 Amps at 240VAC, 1.1 Amps at 120 VAC*
*Controller has 3 Amp fuse rated for 350 VAC
Flow Capacity:
Cv = 0.02 - Standard
Refer to catalog and part number for options.
Supply Voltage
(VAC)
Heater Watts
(W)
Max. Ambient
Temperature
100 - 240 100 - 400
Electrical Housing
149 °F/65 °C
Regulator Body
185 °F/85 °C
All cables, cable glands and conductors need >95 °C rating.
For integral applications the electronics enclosure must engage the regulator assembly by
at least 5 full threads made wrench tight.
