Installation
1.2.2 Electrical requirements
In order to connect the machines to the power supply, you need to install the corresponding
plug according to your equipment:.
WARNING:
Make sure that the plug has not been installed in the power supply.
!
SINGLE-PHASE
GROUNDL3L1
BLACK BLUE GREEN
THREE PHASE
GROUNDL1 L2
BLACK BLUE
L3
GREEN
MODEL SINGLE-PHASE THREE PHASE
EM-10 L6-30 *L15-30
EM-20 L6-30 *L15-30
EM-40 ---
*(CHECK WITH DISTRIBUTOR)
TYPE OF PLUG
WARNING:
Use copper conductors only.
!
DELTA (RED)
* Please consult your distributor in the US and Canada
The EM40 model requires a three-phase connection at 208-230 Volts. The EM10 and EM20
models require a single-phase or three-phase connection at 220 Volts, depending on your
preference.
1.2.2.1 Supply voltage
MODEL MINIMUM SUPPORTED MAXIMUM SUPPORTED RECOMMENDED
EM-10, EM-20
EM-40
208 V 231 V 220 V
