EMG EXB - Page 3

VOLUME
B122rH
Diagram #5
2 Pickups
Toggle Style Select Switch
EXB Control
Master Volume
VOLUME
B122rH
VOLUME
B122rH
BRIDGE PICKUP
NECK PICKUP
BATTERY
NEG (-)
MASTER
VOLUME
T
R
S
OUTPUT CABLE
RED
RED
RED
GROUND
BRIDGE P/U
NECK P/U
OUTPUT
- 9V +
RED
RED
RED
GROUND
BRIDGE P/U
NECK P/U
OUTPUT
2 Pickup Guitars using a selection switch:
Diagrams #5 and #6 show the pickups connected to the B245 Pickup Buss.
To learn more about the B245 Pickup Buss, be sure to go to
http://www.emgpickups.com. More diagrams are available at the EMG website.
The EXB or any EMG Active Tone Control is shown following the pickup buss
and then to the output jack. A master volume could easily follow the EXB
before the output jack.
EXB Page 3
OUTPUT
T
R
S
NK VOLUME
NECK PICKUP
BRIDGE PICKUP
BR VOLUME
BATTERY
NEG (-)
Diagram #6
2 Pickups
Toggle Style Switch
Volume each Pickup (Volumes are independent)
EXB Control
OUTPUT CABLE
NOTE:
REVERSED CONNECTOR
- 9V +
EXB
CONTROL
NOTE:
REVERSED CONNECTOR
EXB
CONTROL
