EMI S1C - PRODUCT INFORMATION; Specifications and Dimensions

www.enviromaster.com
Side Discharge Condensers
22
MOUNTING DIMENSIONS
Model Size A B C D
S1CA/S1HA 9, S1CA/S1HA 2
4 ⅝” 14
11
/
16
” 3” 12
7
/
16
”
S1CA/S1HA 8, S1CA/S1HA 2
4 ⅝” 22
11
/
16
” 3” 12
7
/
16
”
S1CA 3, S1CA 6
7” 23
15
/
16
” 3” 12
7
/
16
”
A
B
C
Easy access interconnects
on back of unit
1/2” Diameter Lag Holes
A
A
B
D
C
SOUND DATA
Size
Btuh
dBA
Heat
Pump
&
Cool
09 59
1 2 59
1 8 62
2 4 63
Cool
Only
30 68
3 6 68
S1C/S1H SPECIFICATIONS AND DIMENSIONS
NOTE: All EMI products are subject to ongoing development. Design and specifications may
change without notice.
PHYSICAL DIMENSIONS
Model Size A B C
S1CA/S1HA 9 24" 15" 36"
S1CA/S1HA 2 24" 15" 36"
S1CA/S1HA 8 32" 15" 36"
S1CA/S1HA 4 32" 15" 40"
S1CA/S1HA 3 38” 15” 44”
S1CA/S1HA 6 38” 15” 48”
SHIPPING WEIGHT
Size Btuh Lbs.
9-12 98
18-24 156
30-36 210
S1C ELECTRICAL SPECIFICATIONS
Model # Volts/HZ/PH
Fan Motor Compressor
Total
AMPS
Min
Volt
M.C.A.
HACR
BRKR
AMPS HP RLA LRA
S1C 9A 115/60/1 1.4 0.125 6.7 29.0 8.1 104 9.8 15
S1C 2A 115/60/1 1.4 0.125 8.4 44.0 9.8 104 11.9 20
S1C 9D 208/230/60/1 0.8 0.125 3.5 19.0 4.3 197 5.2 15
S1C 2D 208/230/60/1 0.8 0.125 4.5 21.0 5.3 197 6.4 15
S1C 8D 208/230/60/1 0.8 0.125 5.4 36.0 6.2 197 7.6 15
S1C 4D 208/230/60/1 0.8 0.125 8.0 53.5 8.8 197 10.8 15
S1C 3D 208/230/60/1 1.8 0.330 9.8 60.0 11.6 197 14.1 20
S1C 6D 208/230/60/1 1.8 0.330 11.8 78.0 13.6 197 16.6 25
Electrical
connections
