NXT90 F v2.2
Service Protocol
NXT 90 F
EN
Service 6 mon 12 mon 24 mon 36 mon
Chassis/seat unit/carry cot function
Check the function of the chassis , that the two locking clips
lock properly on both sides.
Check that the seat/carrycot click on the chassis and it locks
on both sides.
Check the 5 point safety harness on the seat unit by check-
ing that it locks into place.
Check the telescopic height adjustment by lifting/pulling
the handle up and down, the handlebars should be checked
that they lock in each position.
Check that the back rest can be adjusted and locked into
each position.
Check that the footrest on the seat unit can be adjusted
and locked into each position.
Wheels and brakes
Attach the wheels and make sure that the wheels lock into
position.
Check that the parking device locks both rear wheels when
engaged.
Visual overview
Check that all rivets and screws are tightened correctly
Check that all press studs and zippers are intact and
correctly fastened
Check for any other visible deviations on the chassis, fab-
rics, tray/basket and wheels
Lubrication
Clean and lubricate the wheels, axles, chassis locks, footrest
and the safety catch
Other notes (further adjustments or changed details)
