Manual Scooter 2.0 / Scooter S v. 2.2
English
Assembling the vehicle
WARNING
• Make sure that children are kept away from moving parts when
assembling the pram, otherwise they might be at risk of injury.
Unfolding the chassis
• Apply the brake on the pram. To unfold the chassis, pull the handle
upwards, whilst holding down the side of the chassis.
WARNING
• Always make sure that the main locking device (2) and the button
(3) on both sides clicks into locked position .
• The safety catch (1) (secondary locking mechanism) is activated to
prevent unintentional folding if the chassis locks are not locked into
position.
• Make sure, before you use the pram that both chassis locks are in
locked position.
Attaching the wheels
• Remove the plastic protection from the axles. Save them for future
use.
• Press in the hub cap’s release button (4), push the wheel onto the
axles as far as it can go.
Release the button and pull the wheel towards you, until you hear a
denite click and it locks into position. Repeat the same procedure
for all four wheels. Please make sure that the wheels are attached
properly and cannot be pulled off the axle.
IMPORTANT
• The wheels are greased and can leave marks on textiles. Please
use wheel protection indoors to protect your oors.
• Risk of suffocation. Don’t let your child play with or in some other
way handle the plastic protections.
Braking system on the vehicle/releasing the brake
• Brake by pushing the brake bar down (5). Make sure the pins (6)
are moving forward and backwards on both sides.
• Release the brake by lifting the break bar upwards.
WARNING
• Never leave the vehicle with child in it without engaging the braking
system correctly.
• The brake should always be engaged when you lift your child in
and out of the vehicle.
• Never park the vehicle on a slope.
• The vehicle is equipped with cog brakes. Check that there is a
wheel cog on each wheel and that it is rmly attached. Engage the
brake only when the vehicle has come to a standstill.
• Suspend the tray by attaching it to the tubing on the chassis (8).
• Thread the loops onto the tubes behind the springs (8) and afx the
tray round the brake (10).
• When using the brake make sure that the brake pins sit rmly in the
wheel cogs on both sides and locks the rear wheels (7).
