Manual Scooter 2.0 / Scooter S v. 2.2
English
Assembling the vehicle
Assembly of the hood
• Afx the hood clips (18) above the plastic stud (19) on the handle.
Assembly of the footrest fabric
• Press the part of the fabric with the zip fastener through the ope-
ning in the footrest (20).
• Afx the zip fastener (21) under the seat.
• Afx the elastic band (22) round the footrest.
Assembly of the mudguards (Not on the Scooter 360°)
• Thread the mudguard holders onto the axles with the inclination
facing away from the vehicle (23).
• Tighten the screw (24).
• Afx the mudguard (25).
