Manual Toddler Roller v. 3.3
English
3
Assembly of the wheels
• Mount the wheel assembly on the board with the washer between
the wheel assembly and the nut.
• Use the ring spanner to tighten the nut until the upper end of the
nut is level with the end of the bolt..
WARNING!
• Make sure that this is done with both wheels.
• Check that the wheel and the nut are securely attached.
• Clip the brake axle attachments onto the brake axle and bring them
forward around the oval-shaped tubing of the axle. Make sure that
the adaptor tubing is bending over and above the brake.
• On prams with a reversible handle, the adaptor must be mounted
on the side of the pram where the handle is in its original position.
• Make sure the adaptor is facing in the right direction.
Assembly of the adaptor
RIGHT!
WRONG!
• The brake axle attachments can be positioned at different points on
the brake axle depending on the pram model.
