Features & Specifications
Features & Specications
2-Channel D/A conversions:
• from PCM (44.1kHz, 48kHz, 88.2kHz, 96kHz, 176.4kHz, 192kHz) to analog
• from PCM 352DXD and 384DXD to analog via USB
• from DSD and 2xDSD to analog via USB
• from DSD to analog via EMM Optilink (SACD/CD playback)
Supported digital input formats:
• AES/EBU
• Two COAX SPDIF
• Two TOSLINK SPDIF
• EMM Optilink
• USB Audio
Analog outputs and impedances:
• Balanced on XLR (300Ω)
• Unbalanced on RCA (150Ω)
Output levels:
• XLR outputs: 5V (+16dBu)
• RCA outputs: 2.5V (+10dBu)
Note:
1. XLR analog outputs are balanced with pin 2 hot, pin 3 cold and pin 1 ground.
2. For proper digital audio data transfer (especially high resolution PCM and DSD)
appropriate high quality TOSLINK, SPDIF, AES and USB 2.0 cables must be used.
