Emos MD-410 - Direct Current (DC); Alternating Current (AC)

5
AC Voltage
Range Resolution Accuracy
200 mV 100 µV ± (1 % + 5)
2 V 1 mV
± (1.2 % + 5)
20 V 10 mV
200 V 100 mV
300 V 1 V
Frequency range: 40 Hz to 400 Hz
Maximum input voltage: 300 V AC
Response: average value, corresponding to a calibrated eective value of a sine wave.
Direct current (DC)
Range Resolution Accuracy
20 mA 10 µA ± (1 % + 5)
200 mA 100 µA ± (1.5 % + 5)
10 A 10 mA ± (2 % + 5)
Protection against overload:
range μA a mA: fuse 250 mA/300 V, type F, Ø 5 × 20 mm.
range 10 A: fuse 10 A/300 V, type F, Ø 5 × 20 mm.
Maximum input voltage: "VΩmA" socket max 200 mA; "10 A" socket max 10 A (when measuring
currents larger than 2 A; the measuring duration can be max. 10 seconds and measuring may be repeated
again only after 15 minutes)
Alternating current (AC)
Range Resolution Accuracy
20 mA 10 µA ± (1.3 % + 5)
200 mA 100 µA ± (1.8 % + 5)
10 A 10 mA ± (3 % + 5)
Protection against overload:
μA and mA range: fuse 250 mA/300 V, type F, Ø 5 × 20 mm.
10 A range: fuse 10 A/300 V, type F, Ø 5 × 20 mm.
Maximum input current: "VΩmA" socket max. 200 mA; "10 A" socket max. 10 A (when measuring
currents larger than 2 A; the measuring duration must be max. 10 seconds and measuring may be
repeated again only after 15 minutes)
Frequency range: 40 Hz to 400 Hz
Response: average value, corresponding to a calibrated eective value of a sine wave.
Resistance
Range Resolution Accuracy
200 Ω 0.1 Ω
± (1.2 % + 5)
2 kΩ 1 Ω
20 kΩ 10 Ω
200 kΩ 100 Ω
2M Ω 1 kΩ
20 MΩ 10 kΩ ± (1.5 % + 7)
Voltage of an open circuit: 2.8 V
