Digital Input Status [723]
Indicates the status of the Digital inputs. See Fig. 111.
1DigIn 1
2DigIn 2
3DigIn 3
4DigIn 4
5DigIn 5
6DigIn 6
7DigIn 7
8DigIn 8
The positions one to eight (read from left to right) indicate
the status of the associated input:
1High
0Low
The example in Fig. 111 indicates that DigIn 1,
DigIn 3 and DigIn 6 are active at this moment.
Fig. 111 Digital input status example
Communication information
Digital Output Status [724]
Indicates the status of the digital outputs and relays. See Fig.
112.
RE indicate the status of the relays on position:
1Relay1
2Relay2
3Relay3
DO indicate the status of the digital outputs on position:
1DigOut1
2DigOut2
The status of the associated output is shown.
1High
0Low
The example in Fig. 112 indicates that DigOut1 is active
and Digital Out 2 is not active. Relay 1 is active, relay 2 and
3 are not active.
Fig. 112 Digital output status example
Communication information
Analogue Input Status [725]
Indicates the status of the analogue inputs 1 and 2.
Fig. 113 Analogue input status
Communication information
30 Warning 31
31 Warning 32
Modbus Instance no/DeviceNet no: 31016
Profibus slot/index 121/160
Fieldbus format Long
Modbus format UInt
Modbus Instance no/DeviceNet no: 31017
Profibus slot/index 121/161
Fieldbus format
UInt, bit 0=DigIn1, bit
8=DigIn8
Modbus format
Selection Warning message
723 DigIn Status
Stp 1010 0100
Modbus Instance no/DeviceNet no: 31018
Profibus slot/index 121/162
Fieldbus format UInt, bit 0=DigOut1,
bit 1=DigOut2
bit 8=Relay1
bit 9=Relay2
bit 10=Relay3
Modbus format
Modbus Instance no/DeviceNet no: 31019, 31020
Profibus slot/index 121/163, 121/164
Fieldbus format Long, 1=1%
Modbus format EInt
724 DigOutStatus
Stp RE 100 DO 10
725 AnIn 1 2
Stp -100% 65%
