Emotron VSA Series User Manual

56 Programming instructions and menu list Emotron AB 01-3991-11r2
525
Terminal S5 function
(option)
000: Forward
001: Reverse
002: Preset Speed Command 1
003: Preset Speed Command 2
004: Preset Speed Command 3
005: Jog Frequency Command
006: Emergency Stop (E.S.)
007: Base Block (b.b.)
008: Select 2nd acc./dec. time.
009: Reset
010: Up Command
011: Down Command
012: Control signal switch
013: Communication control signal switch
014: Acceleration/ deceleration disable
015: Master/auxiliary speed source select
016: PID function disable
017: Analog frequency signal input (termi-
nal AIN)
018: PID feedback signal (terminal AIN)
019: DC Brake signal
007
526
Terminal S6 function
(option)
009
I/O’s, Analogue outputs
531
Multi-function output
analogue type selec-
tion (0–10 VDC)
000: Output frequency
001: Set frequency
002: Output voltage
003: DC voltage
004: Output current
005: PID feedback signal
000 *1
532
Multi-function ana-
logue output gain (%)
000 to 200% 100 *1
Ta bl e 2 3
Menu Function Description Range/ Code
Factory
Default
Remarks
