ECP210-S6 ECP213-S6 ECP216-S6
Nominal Size 4" (10 cm) 5 ¼" (13 cm) 6 ½" (16.5 cm)
Configuration/System 2-Way 2-Way 2-Way
Nominal Power Handling 120 Wrms 140 Wrms 180 Wrms
Crossover Slopes (MW/TW) 12/12 dB/oct. 12/12 dB/oct. 12/12 dB/oct.
Crossover Frequency 4000 Hz 4000 Hz 4000 Hz
Nominal Impedance 4 ohms 4 ohms 4 ohms
Sensitivity 1W/1m 86 dB 88 dB 91 dB
Frequency Response (- 3dB) 85 Hz – 22 kHz 75 Hz – 22 kHz 55 Hz – 22 kHz
MOUNTING DIMENSIONS
MID/WOOFER
Basket (EURO-DIN) 4" (10 cm) 5 ¼" (13 cm) 6 ½" (16.5 cm)
Mounting Depth 46 mm 59 mm 64 mm
Mounting Diameter 93 mm 116 mm 145 mm
TWEETER
Mounting Diameter (recessed) 46.5 mm 46.5 mm 46.5 mm
Required Mounting Depth (recessed) 19.5 mm 19.5 mm 19.5 mm
TECHNICAL SPECIFICATIONS
