8.0 | Specifications
Channel:
Power Source:
Output waveform:
TENS
IF
Output
Peak Pulse Output
Level
Pulse Width
Pulse Rate
Mode
Output
Peak Pulse Output
Level
Pulse Width
Carrier Rate
Dierence Rate
Treatment
Dual, isolated between channels
700 mAh 4.8V Ni-MH rechargeable battery pack
Symmetric waveform
0~±27V (Loading: 500Ω)
54mA (Loading: 500Ω)
1~20 levels: each level increment ±1.35V
Variable, 50~300 µs
Variable, 2~150 Hz
Burst | Normal | MRW | SD | Bi-Pulse
0~±15V(Loading: 500Ω)
30mA (Loading: 500Ω)
First level: ±1.5V. 2~20 level: each level increment ±0.71V
125 µs for each phase, Fixed
4000Hz
Variable, 1~150 Hz
1/1 abrupt | Continuous | 8/8 abrupt | 10/10 ramped
* All values + or - 10%
