ENCLO EC18006 - Layout Materials

5
SMALL PARTS
LARGE PARTS
Galvinized Steel L
Bracket (2)
⁄" Drill Bit (1)
LAY OUT MATERIALS
A B
H
O
C
G
Top view
Top view
P
K
Short Post (2)
1 ¾" x 1 ¾" x 11"
JI
Short Floor Support (3)
⁄" x 1 ½" x 7 ¼"
Spacer (24)
1 ½" Self-Drilling Stainless
Steel Screw (8)
L
¾" Self-Drilling Stainless
Steel Screw (22)
M
N
Corner Post Cap (4)
Left Post (1)
1 ¾" x 1 ¾" x 44"
Long Board (2)
⁄" x 11" x 44"
Right Post (1)
1 ¾" x 1 ¾" x 44"
Short Board (2)
⁄" x 11" x 7 ¼"
Floor Board (1)
⁄" x 7 ¼" x 44"
D FE
Wide Horizontal Slat (4)
⁄" x 3" x 44"
Long Floor Support (2)
⁄" x 1 ½" x 29 ½"
Thin Horizontal Slat (8)
⁄" x 1 ½" x 44"
