ENDA EC762F - Terminal Connections and Sensors; Terminal Descriptions; Typical Sensor Connections

PNP PROXIMITY SWITCH
GND
OUT
+ 12V
GND
+ 12V
A OUT
B OUT
ENCODER
PNP PROXIMITY SWITCH
PNP PROXIMITY SWITCH
GND
+ 12V
+ 12V
GND
OUT
OUT
TYPICAL SENSOR CONNECTIONS
TERMINAL CONNECTIONS
Terminal descriptions
4 : Reset input.
5 : Solid state out2 (Max 30V 100mA open collector NPN)
6 : Solid state out1 (Max 30V 100mA open collector NPN)
7 : Input for clock pulse 2 (Max 30V 7.5kHz)
8 : Input for clock pulse 1 (Max 30V 7.5kHz)
9 : GND
10 : +12V 50mA auxiliary power supply for sensors.
11,12 : SUPPLY inputs.
13,14,15 : 1. relay output (Max 2A 250V AC)
16,17,18 : 2. relay output (Max 2A 250V AC)
4 RESET IN
5 S.S. OUT2
6 S.S. OUT1
7 CP2 INPUT
8 CP1 INPUT
9 GND
10 +12V 50mA
11
12
13
14
15
16
17
18
OUT1
AC 250V 2A
RESISTIVE
LOAD
OUT2
AC 250V 2A
RESISTIVE
LOAD
ENDA
INDUSTRIAL
ELECTRONICS
EC762F
SN: XXXXXXXXX
230V AC +10% -20%
50/60Hz 7VA
4 RESET IN
5 S.S. OUT2
6 S.S. OUT1
7 CP2 INPUT
8 CP1 INPUT
9 GND
10 +12V 50mA
11
12
13
14
15
16
17
18
OUT1
AC 250V 2A
RESISTIVE
LOAD
OUT2
AC 250V 2A
RESISTIVE
LOAD
ENDA
INDUSTRIAL
ELECTRONICS
EC762F
SN: XXXXXXXXX
230V AC +10% -20%
50/60Hz 7VA
4 RESET IN
5 S.S. OUT2
6 S.S. OUT1
7 CP2 INPUT
8 CP1 INPUT
9 GND
10 +12V 50mA
11
12
13
14
15
16
17
18
OUT1
AC 250V 2A
RESISTIVE
LOAD
OUT2
AC 250V 2A
RESISTIVE
LOAD
ENDA
INDUSTRIAL
ELECTRONICS
EC762F
SN: XXXXXXXXX
230V AC +10% -20%
50/60Hz 7VA
4 RESET IN
5 S.S. OUT2
6 S.S. OUT1
7 CP2 INPUT
8 CP1 INPUT
9 GND
10 +12V 50mA
11
12
13
14
15
16
17
18
OUT1
AC 250V 2A
RESISTIVE
LOAD
OUT2
AC 250V 2A
RESISTIVE
LOAD
ENDA
INDUSTRIAL
ELECTRONICS
EC762F
SN: XXXXXXXXX
230V AC +10% -20%
50/60Hz 7VA
SÝSEL MÜHENDÝSLÝK ELEKTRONÝK SAN. VE TÝC. A.Þ.
Yukarý Dudullu 34775 - ÜMRANÝYE/ÝSTANBUL-TÜRKÝYE
Tel : +90 216 499 46 64 Pbx. Fax : +90 216 365 74 01
url : www.enda.com.tr
Barbaros Cad. Kutup Sok. No:20
5/5
EC762F-E-04
230V AC Supply
230V AC Supply
Switch
Switch
Cable size: 1,5mm²
Cable size: 1,5mm²
Fuse
F 100 mA
250V AC
Fuse
F 100 mA
250V AC
230V AC Supply
Switch
Cable size: 1,5mm²
Fuse
F 100 mA
250V AC
NOTE: NPN PROXIMITY SWITCH connection is the same as PNP PROXIMITY SWITCH connection.
