Owners Manual
Manual del Usuario
Model No.
200209
U.S. Patent Number: 6,470,877; All Other
Foreign Patents May Apply.
WARNING
FOR YOUR SAFETY
For Outdoor Use Only
(Outside any enclosure)
Solamente Para Uso En
Exteriores
(Fuera de cualquier recinto)
WARNING
FOR YOUR SAFETY
Improper installation,
adjustment, alteration,
service or maintenance
can cause injury or property
damage. Read the installation,
operation and maintenance
instructions thoroughly before
installing or servicing this
equipment.

Questions and Answers

  • S
    Scott LopezJul 30, 2025
    Why won't the pilot light on my Endless Summer 200209 Patio Heater?
    • B
      Brittany GibsonJul 31, 2025
      Several factors can prevent the pilot light from igniting on your Endless Summer Patio Heater. It could be due to a closed tank valve (open the valve to resolve this), a blockage in the orifice or pilot tube (clean or replace these parts), air in the gas line (bleed the gas line by pressing the control knob for 1-2 minutes until you smell gas), low gas pressure (replace the tank), or a faulty igniter (use a match to light the pilot and replace the igniter).
  • L
    Louis HarrisAug 5, 2025
    What to do if my Endless Summer 200209 Patio Heater burner won’t light?
    • M
      Miss Olivia Kelley PhDAug 5, 2025
      If the burner on your Endless Summer Patio Heater fails to light, the issue might stem from low gas pressure (turn the tank valve OFF and replace the tank). Alternatively, there could be a blockage in the orifice (clear the blockage), or the control knob might not be in the ON position (turn the control knob to ON).
  • J
    James RamosAug 10, 2025
    What to do if pilot won’t stay lit on Endless Summer Patio Heater?
    • A
      Amy JonesAug 10, 2025
      If the pilot light on your Endless Summer Patio Heater won't stay lit, it could be due to dirt buildup around the pilot (clean the dirt). Another cause might be a loose connection between the gas valve and pilot assembly (tighten the connection and perform a leak check). Lastly, the thermocouple might not be operating correctly (replace the thermocouple).
  • P
    Patrick HarveyAug 15, 2025
    Why is the burner flame low on my Endless Summer Patio Heater?
    • A
      Angel MooreAug 15, 2025
      A low burner flame on your Endless Summer Patio Heater can be attributed to several reasons: low gas pressure (turn the tank valve OFF and replace the tank), outdoor temperature being below 40ºF with a tank less than 1/4 full (use a full tank), a bent or kinked supply hose (straighten the hose), or a blockage in the burner and orifices (check for and clear any blockages).
  • A
    Ashley HarrisAug 19, 2025
    Why does my Endless Summer Patio Heater emitter glow unevenly?
    • M
      mercermarissaAug 19, 2025
      Uneven glowing of the emitter on your Endless Summer Patio Heater can occur due to low gas pressure (turn the tank valve OFF and replace the tank). It may also happen if the base is not on a level surface (place the heater on a level surface), or the burner needs cleaning (clean the burner).
  • B
    Bryan AdamsAug 25, 2025
    What to do if Endless Summer 200209 produces thick black smoke?
    • T
      Tracey PerezAug 25, 2025
      If your Endless Summer Patio Heater is emitting thick black smoke, there is likely a blockage in the burner. Remove the blockage and clean the burner inside and outside.

Summary

General Information and Safety

Initial Safety Warnings

Key warnings for safe operation and potential hazards.

Safety First!

Operational Safety Precautions

Covers safe operating practices, clearances, and environmental considerations.

Hazard Awareness and Precautions

Highlights hazards like high temperatures, children/pets, and flammable materials.

Fuel Safety and Maintenance

Liquid Propane (LP) Gas Safety

Details LP gas characteristics, tank safety, and handling precautions.

Assembly Instructions

Assembly Steps

Step 12: Check for Leaks

Procedure for checking all gas connections for leaks using a soap solution.

Step 11: Connect Gas Line to Tank

Attaching the gas line to the propane tank valve.

Operation

Pre-Operation Checks

Ensuring the heater is ready for safe operation before turning on gas.

Lighting the Pilot and Main Burner

Step-by-step guide for lighting the pilot and main burner.

Operation Procedures

Heater Operation and Re-lighting

Describes normal operation, flame appearance, and re-lighting.

Shutting Down the Heater

Instructions for safely turning off the heater and gas supply.

Operation Checklist

Before Operating Checklist

Comprehensive checklist to ensure safe operation before each use.

Troubleshooting

Maintenance

Storage and Service

Endless Summer 200209 Specifications

General IconGeneral
BrandEndless Summer
Model200209
CategoryPatio Heater
LanguageEnglish
