Understanding the ‘Status’ indicator
Function ‘Status’ Indicator Condition
Power Save Function
‘OFF’
Solid Green Unit is normal and continuous AC Output is
available
Solid Green with alarm beep
every 2 seconds
Unit is detected with either DC Over/Under Voltage
or Over Temperature warning and continuous AC
Output is still available
Power Save Function
‘ON’
Flashing Green Unit is normal and AC Load connected is >10W
Flashing between Amber and
Red
Unit is normal and AC Load connected is <10W or
AC Load connected is reduced from >10W to < 5W
Flashing Green and alarm beep
every 2 seconds
Unit is detected with either DC Over/Under
Voltage or Over Temperature warning and AC Load
connected is > 10W
Flashing between Amber and
Red and alarm beep every 2
seconds
Warning detected with either DC Over/Under
Voltage or Over Temperature AC Load connected
is <10W or AC Load connected is reduced from
>10W to <5W
Power Save Function is
either ‘ON’ or ‘OFF’
Solid Red with alarm beep
every second
No AC Output as unit had shutdown due to either
DC Over/Under Voltage or AC Output Overload
or Over Temperature occurs. See more details
on “Understanding the Warning and Shutdown
Condition” in this manual
Understanding the fan operation:
The fan on the unit is AC load and internal temperature activated. It will automatically turn on when
AC output power exceeds the pre-set values (~ 200W) and turn o when AC output power is reduced
to 150W. It will also automatically turn on when it senses the internal components have reached
approximately 80°C and turn o when temperature drops below 60°C.
Use of the Ignition Start Function on unit:
An ‘Ignition Start’ port is located on the Front AC Panel of the unit using a ¼” width spade terminal.
This port is used for turning the unit On and OFF using a +12V signal. An insulated female connector
is required to connect to the port.
Connecting to +12V will turn ON the unit and removing the +12V signal will turn OFF the unit.
Understanding the Warning and Shutdown Condition
•
Over Temperature Warning: Unit internal temperature is high. Unit requires better ventilation.
•
DC Over Voltage Warning: DC Input Voltage is high and close to the over-voltage shutdown limit.
Check the battery voltage.
