Energetics Basic Bench 3.1 - Page 7

7
Part list – BB 3.1 - 2012
NO.
DESCRIPTION SIZE QTY
1 LEFT UPRIGHT 1
2 RIGHT UPRIGHT 1
3 CROSS BRACE 1
4 MAIN SEAT SUPPORT 1
5 FRONT POST 1
6 SEAT BRACKET 1
7 BACKREST ADJUSTMENT BAR 1
8 LEFT BAR CATCH 1
9 RIGHT BAR CATCH 1
10 LEFT SAFETY CATCH 1
11 RIGHT SAFETY CATCH 1
12 BACKREST SUPPORT 2
13 BRACKET 120mmx50mm 2
14 SEAT PAD 1
15 BACKREST BOARD 1
16 CATCH ANTI-SLIPPING PAD 4
17 BACKREST SUPPORT ANTI-SLIPPING PAD 2
18 SQUARE END CAP 25mm 6
19 END CAP Ø 19mm 8
20 END CAP 60mmx40mm 2
21 END CAP 70mmx50mm 2
22 END CAP Ø 19mmx Ø 17mm 8
23 END CAP PT50mmx100mm 1
24 RUBBER BUMPER 85mmx50mm 2
25 RUBBER BUMPER 146mmx50mm 2
26 BASE END CAP 25mm 5
27 SEAT ADJUSTMENT LOCK PIN 1
28 BUSHING 2
29 NUT CAP M10 12
30 ALLEN BOLT M8 x 40mm 8
31 HEX BOLT M10 x 16mm 1
32 CARRIAGE BOLT M10 x 60mm 2
33 HEX BOLT M10 x 65mm 1
34 CARRIAGE BOLT M10 x 80mm 1
35 CARRIAGE BOLT M10 x 90mm 4
36 HEX BOLT M10 x 155mm 1
37 WASHER Ø 8mm 8
38 WASHER Ø 10mm 10
39 LARGE WASHER Ø 10mm x Ø 30mm 2
40 AIRCRAFT NUT M10 9
ALLENWRENCH (TOOL) #5 1
