Pre-assembly notes
OPEN THE BOXES
Make sure to inventory all the parts that are included in the boxes. Check The Hardware Chart
for a full count of the number of parts included for proper assembly.
GATHER YOUR TOOLS
Before starting the assembly of your unit, gather the necessary tools. Having all of the equipment at
hand
will save time and make the assembly quick and hassle-free.
CLEAR YOUR WORK AREA
Make sure that you have cleared away a large enough space to properly
assemble the unit. Make sure the space is free from anything that may cause
injury during assembly. After the unit is fully assembled, make sure there is a
comfortable amount of free area around the unit for unobstructed operation.
Hardware chart
5 M8 WASHER (T=1.2) 10
6 M8 SPRING WAHER 10
7 M8 CP NUT 2
10 M8*15mm ALLEN HEAD SCREW 8
4 M8*52mm CARRIAGE BOLT 2
21 SEAT KNOB 1
87 ALLEN KEY 1
89 TOOL 1
90 TOOL 1
To Next Page
