1 BASE FRAME 1 46 HANDLEBAR CAP 2
2 FRONT FOOT 1 47 SCREW M8 * 25 mm 2
3 FRONT FOOT COVER(L&R) 2 48 SERVO MOTOR 1
4 M8 * 52 mm CARRIAGE BOLT 2 49 DRIVE WIRE ROD WHEEL 1
5 M8 WASHER (t=1.2) 11 50 CLIP C5 (ID 4.7mm) 1
6 M8 SPRING WASHER 12 51 M6*10mm SCREW 2
7 M8 CAP NUT 2 52 SENSOR BRACKET 1
8 REAR FOOT 1 53 SENSOR WIRE 1
9 REAR FOOT COVER 2 54 #6-32 *12mm SCREW 1
10 M8*15mm ALLEN HEAD SCREW 8 55 WIRE ROD 1
11 LEFT CHAIN COVER 1 56 SMALL SPRING 1
12 RIGHT CHAIN COVER 1 57 M8 NYLON NUT 1
13 HANDLEBAR POST 1 58 M8*52MM HEX HEAD BOLT 1
14 COMPUTER UPPER CABLE 1 59 MAGNETIC HOLDER 1
15 COMPUTER LOWER CABLE 1 60 BEARING (6203ZZ) 4
16 SADDLE POST 1 61 CLIP C17(ID 15.7mm) 3
17 DC CABLE 1 62 MAGNET 1
18 MOVABEL SEAT POST 1 63 REAR PULLEY 1
18A SADDLE POST HOLDER 1 64 WASHER ID17 OD22 <t = 0.3 mm > 1
19 SADDLE 1 65 AXLE FOR PULLEY 1
19A SADDLE BRACKET 1 66 M6*15mm SCREW 4
20 MOVABEL SEAT POST KNOB 1 67 BELT 1
21 SEAT KNOB 1 68 M8*15mm HEX HEAD SCREW 2
22 COMPUTER 1 69 MAGNETIC HOLDER BRACKET 1
23 M5*12mm SCREW 4 70 BRACKET 1
24 HAND PULSE WIRE 1 71 LARGE SPRING 1
25 FOAM GRIP 2 72 SPACER SLEEVE 3
26
HAND PULSE
PE16
2 73 M6*1.5mm WASHER 3
27 HANDLEBAR 1 74 M6*14mm SCREW 3
28 FRONT POST COVER 1 75 BEARING (6300ZZ) 1
29 SADDLE POST COVER 1 76 FRONT PULLEY 1
30 HANDLEBAR SCREW 1 77 FLYWHEEL 1
31 SCREW M5 * 12 mm 14 78 FLYWHEEL AXLE 1
32 3/8" WH NUT 2 79 BEARING (6003ZZ) 2
33 PEDAL (L/R) 1 80 BEARING IC1735-FT 1
34 CROSS FRAME(R) 1 81 WASHER ID30 OD34 (0.8mm) 1
35 ADAPTOR 1 82 BEARING (6000ZZ) 1
36 TURNING PLATE (R) 1 83 M10 WASHER (t=1mm) 1
37 3/8" NUT (t=3mm) 1 84 3/8" NUT (t=7mm) 1
38 TURNUNG PLATE COVER 2 85 CLIP C10(ID 9.1mm) 1
39 SADDLE SUPPORT TUBE INSERT 1 86 CROSS FRAME(L) 1
40 TURNING PEDAL (L) 1 87 BACK HANDLEBAR COVER 1
41 ROUND SCREW FOR ADJ.HEIGHT 2 88 FRONT HANDLEBAR COVER 1
42 M10 WASHER (t=2mm) 3 89 SCREW M3 * 12 mm 2
43 PLASTIC PAD 1 90 SCREW M5 * 10 mm 2
44 FIX PLATE 1
45 PLASTIC BUSH 2
