Energetics CT 680 - Assembly instruction; Step 1

11
Assembly instruction
Step 1
1. Assemble the front stabilizer (4) and rear stabilizer (2) to the main frame (1) by bolt(7),
curved washer(8), spring washer(9) and domed nut (6).
2. Adjust the proper height by turning the wheel of adjustable cap.
2
6
9
8
7
4
9
6
1
8
Step-1
A
(x4)
M8*15L
D15.4
D22
M8*95L
D22
