Liste de pièces de rechange – ST 700 - 2012
Nr.
Description
Qté
Nr.
Description
Qté
1 Cadre principal 1 41 Boulon M8 x 130mm 3
2 Rail glissant 1 42 Boulon M8 x 46mm 2
3 Barre stabilisatrice 1 43 Vis 4 x 60mm 4
4 Protection chaîne gauche 1 44 Boulon M8 x 85mm 2
5 Protection chaîne droite 1 45 Vis M3 x 20mm 9
6 Protection chaîne avant 1 46 Vis M4 x 16mm 10
7 Pédale 2 47 Vis métal 4 x 20mm 3
8 Support arrière 1 48 Vis métal 4 x 25mm 2
9 Roue 1 49 Boulon M5 x 10mm 2
10 Roue sangle 1 50 Vis 6 x 16mm 2
11 Boîtier ressort gauche 1 51 Rondelle 10 x 23mm 2
12 Boîtier ressort droit 1 52 Rondelle 8 x 16mm 4
13 Ressort spirale 1 53 Rondelle 10 x 23mm 4
14 Espacement 1 54 Bouchon R1“ 2
15 Siège 1 55 Ecrou M8 7
16 Support siège 1 56 Ecrou M10 4
17 Barre 1 57 Ecrou 3/8” 2
18 Poignée 2 58 Set câble 1
19 Poulie 2 59 Boulon M6 x 15mm 4
20 Plaquette ressort 1 60 Ecrou Nylon 3/8 1
21 Protection poignée 1 61 Bouchon support arrière 1
22 Tige 1 62 Espacement plastique 1
23 Set magnétique 1 63 Bouchon 50 x 100mm 1
24 Bouton 1 64 Protection acier R15mm 1
25 Bouton ajustement tension 1 65 Vis M4 x 12mm 2
26 Ordinateur 1 66 Vis métal 5 x 11mm 2
27 Sangle pied 2 67 Protection 4
28 Ressort 2 68 Bouchon rouleau 6
29 Sangle 1 69 Ecrou 3/8 x 5T 1
30 Rouleau avant 4 70 Boulon ajustable M6 1
30A Rouleau arrière 2 71 Ecrou M6 1
31 Fondeur 2 72 Bouchon support 1
32 Protection plastique R10mm 2
33 Capteur 1
34 Boîtier poulie 1
35 Bouchon R60mm DIA 2
36 Coussin stabilisateur 4
37 Boulon M10 x 175mm 1
38 Boulon M10 x 132mm 2
39 Boulon M10 x 140mm 1
40 Boulon M10 x 124mm 1
