Energetics ST700 - Page 7

7
Part List – ST 700 - 2012
Nr.
Description
Qty
Nr.
Description
Qty
1 Main Frame 1 41 M8 x 130mm Bolt 3
2 Sliding Rail 1 42 M8 x 46mm Bolt 2
3 Stabilizer Bar 1 43 4 x 60mm Screw 4
4 Left Chain guard 1 44 M8 x 85mm Bolt 2
5 Right Chain guard 1 45 M3 x 20mm Screw 9
6 Front Chain guard 1 46 M4 x 16mm Screw 10
7 Pedal 2 47 4 x 20mm Metal Screw 3
8 Rear Support 1 48 4 x 25mm Metal Screw 2
9 Flywheel 1 49 M5 x 10mm Bolt 2
10 Strap Wheel 1 50 6 x 16mm Screw 2
11 Left Spring Cover 1 51 10 x 23mm Washer 2
12 Right Spring Cover 1 52 8 x 16mm Washer 4
13 Spiral Spring 1 53 10 x 23mm Washer 4
14 Spacer 1 54 R1“ Endcap 2
15 Seat 1 55 M8 Nut 7
16 Seat Support 1 56 M10 Nut 4
17 Handle Bar 1 57 3/8” Nut 2
18 Handle Grip 2 58 Cable Set 1
19 Pulley 2 59 M6 x 15mm Bolt 4
20 Spring Bracket 1 60 3/8 Nylon Nut 1
21 Handle Bar Holder 1 61 Rear Support End Cap 1
22 Shaft 1 62 Plastic Spacer 1
23 Magnetic Set 1 63 50 x 100mm End Cap 1
24 Knob 1 64 R15mm Steel Bushing 1
25 Tension Adjustment Knob 1 65 M4 x 12mm Screw 2
26 Computer 1 66 5 x 11mm Metal Screw 2
27 Foot Strap 2 67 Bearing 4
28 Spring 2 68 Roller Cap 6
29 Strap 1 69 3/8 x 5T Nut 1
30 Upper Roller 4 70 Adj. Bolt M6 1
30A Lower Roller 2 71 M6 Nut 1
31 Caster 2 72 Font Support End Cap 1
32 R10mm Plastic Bushing 2
33 Sensor 1
34 Pulley Housing 1
35 R60mm DIA Endcap 2
36 Stabilizer Cushion 4
37 M10 x 175mm Bolt 1
38 M10 x 132mm Bolt 2
39 M10 x 140mm Bolt 1
40 M10 x 124mm Bolt 1
